2 core 4mm2 ordinary duty flexible cord

PRODUCT REAL SHOT

4mm2 2 core ordinary duty flexible cable

2 x 4mm2 250/440V flexible cord

Large-Size Ordinary Duty Flex Cable for Three-Phase and Equipment Connections

At the upper end of this ordinary-duty range, the 4mm² size is intended for equipment connections where a larger flexible copper conductor is required. The 4mm2 AS/NZS 3191 flexible cord combines annealed copper, V-90 PVC insulation and a 5V-90 PVC sheath in a 250/440V construction, with 2, 3, 4 and 5 core options grouped on one product page. Multi-core configurations can support industrial or office equipment, while selected 4- or 5-core arrangements suit buyers searching for three phase flexible cord solutions with an earth connection. This V90 PVC multicore cable is intended for dry environments and enclosed installations. GERITEL WIRE supports OEM marking, sheath colours, export packing and specification matching.

PRODUCT SPECIFICATIONS

2 core 4 sq mm ordinary duty cable

Applications

Ordinary Duty flexible cords for installation in dry environments only, in conduit or enclosures such as switchboards, control panels, appliances and electrical equipment including radios,desk lamps and office machines. Available in flat and round configurations, as single and multicores - with an earth core in 3 core and above cables for applications such as washing machines and dishwashers. Suitable as leads for industrial and office equipment requiring a three-phase supply and an earth connection.

SPECIFICATIONS
Rated Voltage Uo/U (Um)	250/440V
Temperature Rating	Maximum continuous operating temperature: 90°C
Minimum Bending Radius	6x overall diameter
Conductor	Annealed copper conductor
Insulation	V-90 PVC (Polyvinyl chloride)
Sheath	5V-90 PVC (Polyvinyl chloride)
Sheath Colour	Grey, White, Black, Orange
Core Identification	2 Cores: Brown,Light Blue 3Cores: Brown,Light Blue,Green/Yellow 4 Cores: Brown,Light Blue,White,Green/Yellow 5 Cores: Brown,Light Blue,White,Orange,Green/Yellow

NO.OF CORES
NO.OF CORES	NOMINALCONDUCTOR SIZE mm	NOMINAL INSULATION THICKNESS mm	NOMINAL OUTER SHEATHTH ICKNESS mm	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/100m
2	0.75	0.6	0.8	6.4	5.7
2	1.0	0.6	0.8	6.7	6.5
2	1.5	0.7	0.8	7.7	8.9
2	2.5	0.8	1.0	9.4	14
2	4	0.8	1.0	10.5	18
3	0.75	0.6	0.8	6.8	6.8
3	1.0	0.6	0.8	7.1	7.9
3	1.5	0.7	0.9	8.4	11
3	2.5	0.8	1.1	10.2	17
3	4	0.8	1.1	11.4	23
4	0.75	0.6	0.8	7.4	8.2
4	1.0	0.6	0.9	8.0	9.9
4	1.5	0.7	1.0	9.4	14
4	2.5	0.8	1.1	11.2	21
4	4	0.8	1.1	12.5	29
5	0.75	0.6	0.9	8.3	10
5	1.0	0.6	0.9	8.7	12
5	1.5	0.7	1.1	10.5	17
5	2.5	0.8	1.2	12.4	26
5	4	0.8	1.3	14.1	36

NOMINAL CONDUCTOR SIZE mm	CURRENT CARRYING CAPACITY A
NOMINAL CONDUCTOR SIZE mm	CURRENT CARRYING CAPACITY A	MAXIMUM DC RESSTANCE AT 20 °C Ohm/km	MAXIMUM AC RESISTANCE AT 90°C Ohm/km	SINGLE PHASE VOLTAGE DROP MV/A.m
0.5	3	39.0	49.7	99.4
0.75	7.5	26.0	33.2	66.3
1.0	10	19.5	24.9	49.8
1.5	16	13.3	17	34
2.5	20	7.98	10.2	20.3
4.0	25	4.95	6.31	12.6

CERTIFICATIONS

4mm2 2 core V90 PVC cable

4mm2 2 core 250/440V flexible cable

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Household Appliances

Industrial Equipment

Office Equipment

CASE

Bakery Processing Equipment Project – United States

multicore annealed copper PVC flexible cord

Industrial Control Equipment

V90 insulated 5V90 sheathed multicore flex cable

Simply Shaker Laundry, Kenthurst

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

plain annealed copper ordinary duty flexible cable

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

flexible stranded copper PVC insulated cable 250/440V

round multicore V90 PVC flexible cord construction

V90 PVC insulated flexible cable 250/440V

GLOBAL CERTIFICATIONS

PVC insulated PVC sheathed flexible cord

CUSTOMER PHOTOS

heat resistant V90 PVC flexible cord

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

ordinary duty PVC insulated multicore cable

250 440 volt V90 multicore flexible cable

6x overall diameter bending radius flexible cord

minimum bending radius 6x OD flexible cable

V90 cord maximum continuous operating temperature 90C

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

250/440V flexible cable minimum bending radius

FAQ

Can you provide a datasheet for each conductor size?

Yes. GERITEL WIRE can prepare or provide a technical datasheet for the selected Class 5 Copper Flexible Cord, including the confirmed core number, conductor size, construction and dimensional information available for that item. This is especially useful when 0.75, 1.0, 1.5, 2.5 and 4mm² products share one family name but differ in diameter, weight and electrical characteristics.

Does AS/NZS 3191 cover the whole finished cord?

AS/NZS 3191 is the finished flexible-cord product standard, while conductor and material requirements may reference other standards. When a buyer specifies AS/NZS 3191 Flexible Cord, GERITEL WIRE separates the finished-cord standard from conductor and material requirements in the technical submission. That makes it easier for engineers to see what governs the complete cable and what governs individual components.

What is the role of AS/NZS 60227 on this product?

Some Australian market products list AS/NZS 60227 alongside AS/NZS 3191 for V-90 ordinary-duty cords. For 4mm² V90 Flexible Cord, the applicable standard statement should follow the actual certificate and test basis for the ordered product. GERITEL WIRE can align quotations, datasheets and approval documents so customers do not end up with conflicting standard references across different files.

Can I use an IEC flexible cord instead of an AS/NZS 3191 cord?

Not automatically. Similar-looking cords can have different voltage designations, constructions, markings and approval routes. If the project specifies AS/NZS 3191 Flexible Cord, GERITEL WIRE recommends matching the required AS/NZS standard first, then comparing any IEC equivalent only when the equipment designer or local authority accepts it. We can help prepare the comparison information for the buyer's technical review.
