200 mM THHN/THWN-2 – Large-Capacity Feeder for Service Entrance and Main Distribution

For buildings with substantial power requirements, 200 mm² THHN/THWN-2 delivers the necessary capacity. Constructed with pure copper conductor (stranded or solid), PVC insulation with a nylon jacket, and certified to UL83. Rated 600V. The 200 mm² cross-section handles large loads with minimal voltage drop. The nylon jacket provides effective protection against abrasion during installation and moisture ingress in damp locations. This wire is commonly specified for service entrance conductors, main distribution panel feeders, and connections to large equipment in commercial and industrial facilities.

PRODUCT SPECIFICATIONS

THHN Wire DTI BPS certification

Size of Conductor			No. & Nominal Diameter of Wire	Wall Thickness		Approxi mate Overall Diameter	Minimum Insulation Resistance	Ampacity			Cable Nominal Weight
MM	Approxi mate AWG		MM	MM		MM	M-Ohm-Km	70℃ Wet		90℃ Dry	KG/KM
Solid				PVC	NYLON				THWN	THHN
1.6		14	1x1.60	0.4	0.10	2.60	130		35	35	22.62
2.0		12	1x2.0	0.4	0.10	3.00	110		40	40	33.57
2.6		10	1x2.6	0.5	0.10	3.80	120		55	55	55.78
3.2		8	1x3.2	0.8	0.13	5.06	120		75	75	88.33
Stranded
2.0		14/7	7x0.60	0.4	0.10	2.80	130		30	35	23.51
3.5		12/7	7x0.80	0.4	0.10	3.40	110		35	40	39.12
5.5		10/7	7x1.00	0.5	0.10	4.20	120		50	55	60.56
8.0		8/7	7x1.20	0.8	0.13	5.46	120		65	75	91.95
14		6/7	7x1.60	0.8	0.13	6.66	100		95	105	151.77
22		4/7	7x2.0	1.0	0.15	8.30	100		130	140	236.65
30		2/7	7x2.30	1.0	0.15	9.20	100		160	170	306.50
38		1-19	19x1.60	1.3	0.18	10.96	100		185	195	409.82
50		1/0-19	19x1.80	1.3	0.18	11.96	100		220	235	509.05
60		2/0-19	19x2.00	1.3	0.18	12.96	80		250	260	618.96
80		3/0-19	19x2.30	1.3	0.18	14.46	80		300	320	804.44
100		4/0-19	19x2.60	1.3	0.18	15.96	80		355	370	1013.94
125		250MCM	37x2.10	1.6	0.18	18.26	80		400	420	1286.37
150		300MCM	37x2.30	1.6	0.20	19.70	80		440	475	1542.02
		350MCM	37x2.47	1.6	0.20	20.90	80		505	570	1783.07
200		400MCM	37x2.60	1.6	0.20	21.80	60		540	570	1946.72
		500MCM	37x2.95	1.6	0.20	24.25	60		620	655	2486.02
250		500MCM	61x2.30	1.6	0.20	24.30	60		620	655	2437.34
		600MCM	61x2.52	1.8	0.23	26.76	60		690	715	2995.93
325		650MCM	61x2.60	1.8	0.23	27.46	60		720	770	3191.58
		750MCM	61x2.82	1.8	0.23	29.36	60		785	845	3719.63
400		800MCM	61x2.90	1.8	0.23	30.16	60		810	875	3927.55
500		1000MCM	61x3.20	1.8	0.23	32.86	60		930	995	4750.91

CERTIFICATIONS

UL 83 copper building wire wet and dry locations

PACKAGING

UL 83 copper building wire wet location wire

Plastic Reel

Small Wooden Reel

UL 83 copper building wire for rainy season projects

Large Wooden Reel

APPLICATION

THHN wire Philippines for commercial building wiring

Cable Tray Raceway Systems

Copper THHN/THWN-2 Wire Philippines for industrial wiring

Underground Conduit Installation

UL 83 THHN/THWN-2 wire for building power distribution

Branch Circuit Wiring

CASE

THHN Wire for electrical permit Philippines

Bonifacio Global City, Taguig

SM Mall of Asia ,Pasay

Copper THHN/THWN-2 Wire Philippines for control circuits

Clark Freeport Zone ,Pampanga

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

UL 83 THHN/THWN-2 wire for factory wiring

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

UL 83 THHN/THWN-2 wire for hotel electrical wiring

Copper THHN/THWN-2 Wire Philippines for data center wiring

UL 83 THHN/THWN-2 wire for school building wiring

UL 83 THHN/THWN-2 wire for condominium electrical wiring

UL 83 THHN/THWN-2 wire for solar project conduit wiring

GLOBAL CERTIFICATIONS

THHN wire Philippines 75C ampacity

CUSTOMER PHOTOS

THHN wire Philippines heat resistant 600V

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

THHN wire Philippines for tropical climate Philippines

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

UL 83 copper building wire indoor conduit

THHN wire Philippines for conduit wiring

UL 83 THHN/THWN-2 wire for electrical panel

Copper THHN/THWN-2 Wire Philippines for lighting circuits

UL 83 THHN/THWN-2 wire for control circuits

THHN wire Philippines for hotel electrical wiring

UL 83 THHN/THWN-2 wire for warehouse wiring

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

Copper THHN/THWN-2 Wire Philippines for condominium electrical wiring

FAQ

Is 200 mm² suitable for a 400A service?

200 mm² is typically rated for 400A at 75°C, making it suitable for 400A services when termination ratings allow. Verify the specific ampacity with the manufacturer's data sheet.

What pulling tension is required for 200 mm²?

Substantial. Use a pulling grip rated for the conductor size and a winch or capstan with sufficient capacity. Lubricant is essential.

Can 200 mm² be used in cable tray?

Yes, if installed according to code requirements for conductor spacing and tray fill. The PVC-nylon insulation provides adequate protection for tray installations.

What is the typical application for 200 mm² in industrial settings?

Main feeders to large manufacturing equipment, primary feeders in distribution systems, and connections from transformers to switchgear.
