Building Construction Wire Copper Electrical Wire

Building Construction Wire Copper Electrical Wire
Details:
·Conductor:Pure copper
·Conductor Type:Stranded/Solid
·Insulation:PVC
·Voltage Rating:600V
·Temperatura:90℃
·Size Range:14AWG~1000Kcmil
·Standard:UL83
·Single core ·Color:Black,Red,Blue,Yellow,White,Orange,Green,Purple,Pink,Grey
Send Inquiry
Download
Description
Technical Parameters
Certification

copper 12 AWG 600V building wire

PRODUCT REAL SHOT



commercial 12 AWG 600V building wire
industrial 12 AWG 600V building wire
electrical 12 AWG 600V building wire

600V 12 AWG 600V building wire

Dual Rated Building Wire for Contractor and Distributor Supply
Built for professional building wiring, GERITEL WIRE building construction wire gives contractors, wholesalers and project buyers a clear product option for 600V circuits. Its copper conductor is protected by PVC insulation and a nylon covering, a construction commonly associated with THHN/THWN-2 building wire for conduit and raceway installation. For projects requiring dual rated building wire, this product is relevant to conduit, raceway, feeder and branch-circuit applications when installed under the applicable electrical rules. GERITEL WIRE can coordinate conductor-size review, requested colors, custom printing, packaging and shipment documentation, helping international buyers reduce avoidable order mismatches.
PRODUCT SPECIFICATIONS



single conductor 12 AWG 600V building wire

Conductor
Size

 Conductor
Stranding		 Insulation
Thickness 		Jacket Thickness Nominal
O.D. 		Approx Net Weight Allowable Ampacities(1)
@30℃ Ambient
AWG/Kcmil Number of Strands mils mils Inch lbs/1000ft 75℃ 90℃
14 1 15 4 0.101 17 20 25
12 1 15 4 0.119 25 25 30
10 1 20 4 0.150 39 35 40
14 19 15 4 0.113 16 20 25
12 19 15 4 0.133 25 25 30
10 19 20 4 0.164 39 35 40
8 19 30 5 0.218 63 50 55
6 19 30 5 0.252 96 65 75
4 19 40 6 0.325 153 85 95
3 19 40 6 0.353 193 100 115
2 19 40 6 0.381 236 115 130
1 19 50 7 0.437 300 130 145
1/0 19 50 7 0.480 373 150 170
2/0 19 50 7 0.522 464 170 195
3/0 19 50 7 0.572 577 200 225
4/0 19 50 7 0.629 719 230 260
250 37 60 8 0.703 857 255 290
300 37 60 8 0.758 1019 285 320
350 37 60 8 0.808 1181 310 350
400 37 60 8 0.851 1342 335 380
500 37 60 8 0.937 1665 380 430
600 61 70 9 1.036 2002 420 475
750 61 70 9 1.134 2465 475 535
1000 61 70 9 1.273 3296 545 615

CERTIFICATIONS



PVC nylon 12 AWG 600V building wire

PACKAGING



building 12 AWG 600V building wire

Plastic Reel

conduit 12 AWG 600V building wire

Small Wooden Reel

raceway 12 AWG 600V building wire

Large Wooden Reel

APPLICATION



power 12 AWG 600V building wire
Cable Tray Raceway Systems
quality 12 AWG 600V building wire
Underground Conduit Installation
certified 12 AWG 600V building wire
Branch Circuit Wiring
CASE



premium 12 AWG 600V building wire

Mayo Clinic Hospital, Saint Marys Campus

bulk 12 AWG 600V building wire

30 Hudson Yards

OEM 12 AWG 600V building wire

Stanford University California USA

WHY CHOOSE US



30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

export 12 AWG 600V building wire

15K
Finished Projects
150+
professional staff
15K
happy clients
92+
awards & certifacates
PLANT EQUIPMENT



project 12 AWG 600V building wire

UL listed 12 AWG UL listed building wire

copper 12 AWG UL listed building wire

commercial 12 AWG UL listed building wire

electrical 12 AWG UL listed building wire

600V 12 AWG UL listed building wire

GLOBAL CERTIFICATIONS



single conductor 12 AWG UL listed building wire

CUSTOMER PHOTOS


PVC nylon 12 AWG UL listed building wire

INTERNATIONL TRANSPORTATION



01

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

02

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

03

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

building 12 AWG UL listed building wire
COOPERATIVE PARTNER



We are looking for a cooperative partner to expand our business.

conduit 12 AWG UL listed building wire
raceway 12 AWG UL listed building wire
power 12 AWG UL listed building wire
quality 12 AWG UL listed building wire
certified 12 AWG UL listed building wire
premium 12 AWG UL listed building wire
bulk 12 AWG UL listed building wire
OEM 12 AWG UL listed building wire
export 12 AWG UL listed building wire
project 12 AWG UL listed building wire
How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

supplier 12 AWG UL listed building wire
FAQ



Can I combine THHN with other cable products in one shipment?
Consolidated shipments can reduce logistics complexity when packaging, weight, documentation and delivery dates for all products are compatible. Buyers evaluating THHN consolidated shipment can work with GERITEL WIRE on document review, sample confirmation, project quantities and repeat-order consistency.
Does copper price affect quotation validity?
Yes. Because copper represents a major share of material cost, suppliers often give quotations a defined validity period or use a copper-price adjustment mechanism. GERITEL WIRE can quote THHN copper price validity based on the actual project BOM rather than relying on a generic product name, helping reduce specification mismatches.
Can stock and made-to-order THHN be shipped together?
Yes, if the buyer accepts the combined lead time. Alternatively, available stock can ship first while custom colors or packaging are produced. For international orders of THHN stock and production order, GERITEL WIRE can coordinate technical confirmation, color and size selection, printing, packing and shipment documentation.
Can I request export-grade wooden reels?
Yes. For heavy or long-length conductors, robust wooden reels are commonly chosen for international transportation and repeated handling. GERITEL WIRE can support THHN export wooden reel distributors and contractors with product-data confirmation, OEM requirements, batch identification and export-ready packing.
