150mm flexible earth cable

PRODUCT REAL SHOT

150mm green yellow earth cable

Green Yellow Utility Grounding Wire for Critical Infrastructure

Built for low-resistance grounding for critical infrastructure, this 150mm green yellow grounding cable uses fine-stranded annealed copper with V-90 PVC insulation and green/yellow identification. Rated 0.6/1 kV, it supports protective earthing and bonding in generator installations and utility panels. Flexible construction eases routing through ducts, bends and crowded terminals while helping installers form neat, secure connections. Specify the utility earth conductor when a dependable Class 5 copper PE wire is needed for fixed electrical installations rather than continuous motion. Supplied in cut lengths or drums, the infrastructure bonding cable can support OEM, switchboard and project orders.

PRODUCT SPECIFICATIONS

150mm green yellow flexible cable

Cable description

Flexible PVC insulated only earth cable to AS/NZS 5000.1

Applications

For use as protective earth in electrical installations. For use where improved aging properties to those of 75°C PVC are required because of higher ambient temperatures. Suitable for glanding.

SPECIFICATIONS
Approvals	Suitable for fixed applications only in accordance with AS/NZS 3000 +AS/NZS 5000.1
Behaviour in flame and fire	Flame propagation=AS/NZS 1660.5.6
Temperature range	Maximum operating temperature: +90°C Minimum operating temperature: 0 °C
Minimum bending radius	Installed cables: 4D During installation: 6D
Resistance to	Chemical exposure: Occasional Mechanical impact: Light Water exposure: Occasional condensation Solar radiation and weather exposure: Occasional
Cable design	Conductor: Flexible bunched annealed copper conductor to AS/NZS 1125 (Class 5) Insulation: V-90 PVC Colour: Green/yellow
Installation conditions	Industrial equipment In conduit Machines Internal wiring

For fixed installation

Conductor
Conductor		Cable				Min. installed bending radius mm
Nominal C.S.A mm²	Nominal diameter mm	Nominal nsulation thickness mm	Overall diameter		Approx. mass kg/100 m
Nominal C.S.A mm²	Nominal diameter mm	Nominal nsulation thickness mm	Minimum mm	Maximum mm	Approx. mass kg/100 m
1.0	1.3	0.8	2..9	3.0	1.6	12
1.5	1.5	0.8	3.1	3.2	2.0	13
2.5	2.0	0.8	3.6	3.7	3.0	15
4	2.7	1.0	4.6	4.7	5.4	19
6	3.5	1.0	5.4	5.6	8.0	22
10	4.2	1.0	6.1	6.3	11	25
16	5.3	1.0	7.2	7.4	16	30
25	6.7	1.2	8.9	9.1	25	40
35	7.9	1.2	10.1	10.3	34	45
50	9.5	1.4	12.1	12.3	49	50
70	11.3	1.4	13.9	14.2	67	60
95	13.0	1.6	16.0	16.2	89	65
120	14.7	1.6	17.6	17.9	112	75
150	16.5	1.8	19.8	20.2	140	85
185	18.2	2.0	21.9	22.2	170	90
240	20.9	2.2	25	25.4	223	105
300	23.5	2.4	27.9	28.4	279	115
400	26.9	2.6	31.7	32.2	365	130

Electrical characteristics

Conductor nominal C.S.A. mm²	MaximumD.C. resistance at 20°C Ω/km	Reactance per core (Trefoil, Touching) Ω/km


1.0	19.5	0.116
1.5	13.3	0.109
2.5	7.98	1.101
4	4.95	0.100
6	3.30	0.0954
10	1.91	0.0876
16	1.21	0.0835
25	0.780	0.0829
35	0.554	0.0801
50	0.386	0.0799
70	0.272	0.0773
95	0.206	0.0771
120	0.161	0.0753
150	0.129	0.0755
185	0.106	0.0754
240	0.0801	0.0749
300	0.0641	0.0747
400	0.0486	0.0738

CERTIFICATIONS

150mm flexible grounding cable

150mm flexible ground wire

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Industrial Control Panel

Renewable Energy Power Connection

Switchboard Wiring

CASE

150mm flexible protective earth conductor

Adelaide Airport Switchboard Upgrade

Industrial Main Switchboard Power Distribution

Main Switchboard Flexible Cable Replacement

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

GLOBAL CERTIFICATIONS

flexible bunched copper earth wire

CUSTOMER PHOTOS

plain annealed copper flexible earth cable

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

flexible circular copper earth conductor

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

What does AS/NZS 1125 Class 5 mean for the conductor?

AS/NZS 1125 is the conductor standard referenced for the Class 5 bunched annealed copper conductor. Flame propagation is assessed to AS/NZS 1660.5.6. GERITEL WIRE can prepare a technical submittal based on the confirmed project specification. Relevant product terms are SAA certified flexible earth cable, AS/NZS 5000.1 green yellow cable and AS/NZS 1125 Class 5 earth conductor.

How does AS/NZS 3000 affect installation of this cable?

AS/NZS 3000 governs how the cable is selected, identified, routed, protected and terminated in the electrical installation. SAA certification is split between SAA241316 and SAA241317 according to conductor size. GERITEL WIRE supports mixed-size project orders and can identify the correct SAA certificate by conductor size. Relevant product terms are SAA certified flexible earth cable, AS/NZS 5000.1 green yellow cable and AS/NZS 1125 Class 5 earth conductor.

What does AS/NZS 1660.5.6 test?

It evaluates vertical flame propagation on a single insulated wire or cable. It is not the same as a fire-resistance or circuit-integrity test. The conductor is flexible bunched annealed copper to AS/NZS 1125 Class 5. GERITEL WIRE can provide production records and inspection information for project review. Relevant product terms are SAA certified flexible earth cable, AS/NZS 5000.1 green yellow cable and AS/NZS 1125 Class 5 earth conductor.

Does passing AS/NZS 1660.5.6 make the cable fire resistant?

No. Flame-propagation compliance does not mean the cable will maintain circuit operation during a fire. The V-90 PVC insulation is manufactured to AS/NZS 5000.1 for 0.6/1kV service. GERITEL WIRE can help compare the standard product with alternative constructions for harsher environments. Relevant product terms are AS/NZS 1660.5.6 earth cable, V-90 PVC flexible earth cable and flame propagation tested earth cable.
