Name: China 240mm Flexible Ground Conductor 600/1000V Green Yellow Manufacturers Suppliers Factory
Brand: GERITEL
SKU: 309983897

Description

Technical Parameters

Certification

240mm flexible earth cable

PRODUCT REAL SHOT

240mm green yellow earth cable

Class 5 Substation Grounding Cable for Renewable Energy Projects

Built for large-conductor flexibility for complex installations, this 240mm green yellow earth conductor uses fine-stranded annealed copper with V-90 PVC insulation and green/yellow identification. Rated 0.6/1 kV, it supports protective earthing and bonding in substations and renewable-energy plants. Flexible construction eases routing through ducts, bends and crowded terminals while helping installers form neat, secure connections. Specify the substation PE cable when a dependable 0.6/1kV grounding wire is needed for fixed electrical installations rather than continuous motion. Supplied in cut lengths or drums, the renewable energy bonding conductor can support OEM, switchboard and project orders.

PRODUCT SPECIFICATIONS

240mm green yellow flexible cable

Cable description

Flexible PVC insulated only earth cable to AS/NZS 5000.1

Applications

For use as protective earth in electrical installations. For use where improved aging properties to those of 75°C PVC are required because of higher ambient temperatures. Suitable for glanding.

SPECIFICATIONS
Approvals	Suitable for fixed applications only in accordance with AS/NZS 3000 +AS/NZS 5000.1
Behaviour in flame and fire	Flame propagation=AS/NZS 1660.5.6
Temperature range	Maximum operating temperature: +90°C Minimum operating temperature: 0 °C
Minimum bending radius	Installed cables: 4D During installation: 6D
Resistance to	Chemical exposure: Occasional Mechanical impact: Light Water exposure: Occasional condensation Solar radiation and weather exposure: Occasional
Cable design	Conductor: Flexible bunched annealed copper conductor to AS/NZS 1125 (Class 5) Insulation: V-90 PVC Colour: Green/yellow
Installation conditions	Industrial equipment In conduit Machines Internal wiring

For fixed installation

Conductor
Conductor		Cable				Min. installed bending radius mm
Nominal C.S.A mm²	Nominal diameter mm	Nominal nsulation thickness mm	Overall diameter		Approx. mass kg/100 m
Nominal C.S.A mm²	Nominal diameter mm	Nominal nsulation thickness mm	Minimum mm	Maximum mm	Approx. mass kg/100 m
1.0	1.3	0.8	2..9	3.0	1.6	12
1.5	1.5	0.8	3.1	3.2	2.0	13
2.5	2.0	0.8	3.6	3.7	3.0	15
4	2.7	1.0	4.6	4.7	5.4	19
6	3.5	1.0	5.4	5.6	8.0	22
10	4.2	1.0	6.1	6.3	11	25
16	5.3	1.0	7.2	7.4	16	30
25	6.7	1.2	8.9	9.1	25	40
35	7.9	1.2	10.1	10.3	34	45
50	9.5	1.4	12.1	12.3	49	50
70	11.3	1.4	13.9	14.2	67	60
95	13.0	1.6	16.0	16.2	89	65
120	14.7	1.6	17.6	17.9	112	75
150	16.5	1.8	19.8	20.2	140	85
185	18.2	2.0	21.9	22.2	170	90
240	20.9	2.2	25	25.4	223	105
300	23.5	2.4	27.9	28.4	279	115
400	26.9	2.6	31.7	32.2	365	130

Electrical characteristics

Conductor nominal C.S.A. mm²	MaximumD.C. resistance at 20°C Ω/km	Reactance per core (Trefoil, Touching) Ω/km


1.0	19.5	0.116
1.5	13.3	0.109
2.5	7.98	1.101
4	4.95	0.100
6	3.30	0.0954
10	1.91	0.0876
16	1.21	0.0835
25	0.780	0.0829
35	0.554	0.0801
50	0.386	0.0799
70	0.272	0.0773
95	0.206	0.0771
120	0.161	0.0753
150	0.129	0.0755
185	0.106	0.0754
240	0.0801	0.0749
300	0.0641	0.0747
400	0.0486	0.0738

CERTIFICATIONS

240mm flexible grounding cable

240mm flexible ground wire

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Industrial Control Panel

Renewable Energy Power Connection

Switchboard Wiring

CASE

240mm flexible protective earth conductor

Adelaide Airport Switchboard Upgrade

Industrial Main Switchboard Power Distribution

Main Switchboard Flexible Cable Replacement

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

flexible earth cable for higher ambient temperature

GLOBAL CERTIFICATIONS

improved ageing PVC earth cable

CUSTOMER PHOTOS

AS/NZS 5000.1 flexible earth cable

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

AS/NZS 5000.1 protective earth conductor

Australian standard flexible earth cable

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

New Zealand standard flexible earth cable

FAQ

Is 630mm² covered by SAA241317?

Yes. 630mm² is the upper confirmed size in the SAA241317 range. The conductor is flexible bunched annealed copper to AS/NZS 1125 Class 5. GERITEL WIRE can prepare a technical submittal based on the confirmed project specification. Relevant product terms are SAA241317 flexible earth cable, 25mm²–630mm² SAA earth cable and large flexible earth conductor.

Can I verify the SAA certificate number before ordering?

Yes. Request the certificate copy and confirm that the quoted conductor size, model description and certificate number agree. The V-90 PVC insulation is manufactured to AS/NZS 5000.1 for 0.6/1kV service. GERITEL WIRE supports mixed-size project orders and can identify the correct SAA certificate by conductor size. Relevant product terms are SAA certified flexible earth cable, AS/NZS 5000.1 green yellow cable and AS/NZS 1125 Class 5 earth conductor.

Can GERITEL WIRE provide a copy of SAA241316?

Yes. GERITEL WIRE can provide SAA241316 for the 1mm²–16mm² range. The cable is suitable for fixed applications under AS/NZS 3000 and is suitable for glanding. GERITEL WIRE can provide production records and inspection information for project review. Relevant product terms are SAA241316 flexible earth cable, 1mm²–16mm² SAA earth cable and GERITEL WIRE SAA cable.

Can GERITEL WIRE provide a copy of SAA241317?

Yes. GERITEL WIRE can provide SAA241317 for the 25mm²–630mm² range. The confirmed operating range is 0°C to +90°C. GERITEL WIRE can help compare the standard product with alternative constructions for harsher environments. Relevant product terms are SAA241317 flexible earth cable, 25mm²–630mm² SAA earth cable and large flexible earth conductor.
