2 AWG UL44 AA8000 Aluminum XHHW / XHHW-2 Wire AA8000 Aluminum Conductor For Airport Power Systems

Since AA8000 aluminum has a conductivity of approximately 61.8% IACS, it has higher resistance per foot than copper of the same gauge, so voltage drop must be verified for long runs per NEC requirements. For 2 AWG aluminum XHHW-2 wire, design engineers should calculate line loss based on actual circuit length, load current and power factor, and upsize the conductor if needed to keep voltage drop within code limits. The lightweight nature of aluminum still delivers lower total installed cost than copper for most long-distance airport distribution runs, even with a slight gauge increase.

The XLPE thermoset insulation of XHHW-2 wire has good resistance to mild oils, grease and common airport chemical agents, and is suitable for installation in conduit in apron and maintenance areas with occasional exposure. It is not designed for continuous direct immersion in deicing fluids or fuel; when installed in sealed raceway systems as required by code, it provides reliable long-term performance in airport ground support zones with occasional chemical splashes.

When operated within its rated temperature and voltage limits and installed per NEC guidelines, AA8000 aluminum XHHW-2 wire has a design service life of 30+ years in airport power systems. The main factors that shorten service life are sustained operation above rated temperature, chronic moisture intrusion into damaged conduit, and improperly crimped terminals. For airport 24-hour continuous load scenarios, selecting XHHW-2 grade and following proper termination procedures is critical to achieving full design life.

Standard 2 AWG XHHW aluminum wire is suitable for dry, climate-controlled indoor areas such as terminal public zones, office wings and upper-floor electrical rooms, where it delivers reliable 90°C dry performance at a lower cost. XHHW-2 grade is required for apron underground conduit, baggage handling basements, aircraft maintenance bays, outdoor lighting circuits and any area with sustained humidity or moisture exposure, as it maintains full 90°C performance in wet conditions to avoid premature aging and code non-compliance.
