35kV 133% I.L. Copper 420 Mils TR-XLPE CN Wire with Conductor Shield & Full Concentric Neutral

This 35kV 133% I.L. Copper Medium Voltage Underground Distribution MV-90 Cable 420 mils is fully recognized as MV-90 Primary UD Cable primary UD rated, available as standard 35kV unfilled TR-XLPE cable MV-90 Primary UD Cable, built premium TR-XLPE CN LLDPE Cable with conductor shield, and engineered heavy-duty MV-90 Primary UD Cable with full concentric neutral. It adopts Class B compressed unfilled copper conductor, extruded thermoset semi-conducting conductor shield, 420 mils tree-retardant TR-XLPE insulation at 133% insulation level, complete helical copper concentric neutral and sunlight-resistant LLDPE outer jacket, featuring high dielectric strength and excellent water tree resistance for direct burial and underground duct bank power distribution in wet/dry utility sites, rated 90°C continuous operation and fully compliant with UL 1072, ICEA and RUS specifications.

PRODUCT SPECIFICATIONS

TR-XLPE CN LLDPE Cable with neutral wire

Product Description

The Medium Voltage Underground Distribution (UD) cables consist of an Copper (filled or unfilled) conductor, covered with tree-retardant cross-linked polyethylene (TR-XLPE), a concentric neutral of helically applied copper wires, and a linear low-density polyethylene (LLDPE) jacket with 3 extruded red stripes.

Applications

Suitable for underground primary power applications
For wet or dry locations
For direct burial or in duct

Features

High dielectric strength
Low moisture absorption
Low dielectric loss
Excellent resistance to treeing
Jacket is sunlight-resistant
Designed to operate continuously at a conductor temperature not exceeding

» 90°C for normal operations

» 130°C for emergency overload

» 250°C for short circuit

SPECIFICATIONS
Conductor Count	1 conductor
Conductor	Fully annealed bare copper Class B compressed strand (filled or unfilled)
Gauge Sizes	Available in 2 AWG through 1000 kcmil
Conductor Strand Shield	Extruded thermoset semi-conducting polymer over the conductor *Super-Smooth is available upon request
Insulation	Tree-Retardant Cross-linked Polyethylene (TR-XLPE)
Insulation Shield	Extruded thermoset semi-conducting polymer over the insulation
Neutral	Helically applied, annealed, solid bare copper wires
Jacket	Linear Low-Density Polyethylene (LLDPE) *Moisture blocked jacket is available upon request
Jacket Marking	00000 FT GREATER WIRE CABLE XXAWG (KCMIL) CU (FS) 1/C XXKV XXX% INSUL LEVEL XXXMILS TRXLPE AA X #BB LLDPE JKT TYPE MV-90 (UL) MADE IN USA MMDDYYYY (LIGHTNING BOLT)
Packaging	Non-returnable wood reels in a variety of lengths and dimensions
Performance Compliances	ASTM B3 ASTM B8 ICEA S-94-649 ICEA T-31-610 (water block compliance), as needed ICEA T-34-664 (moisture blocked jacket), as needed AEIC CS8 UL 1072 (MV-90) RUS U1

Copper Unfilled/Filled, 35kV 133% I.L., 420 mils

Conductor Size AWG/Kcmil	Nom. Conductor Diameter in (mm)	Insulation Diameter in (mm)	Concentric Neutral No. x AWG	Jacket Thickness in (mm)	Approx. Overall Diameter in (mm)	Approx. Net Weight lbs/kft (kg/km)	Ampacity
Conductor Size AWG/Kcmil	Nom. Conductor Diameter in (mm)	Insulation Diameter in (mm)	Concentric Neutral No. x AWG	Jacket Thickness in (mm)	Approx. Overall Diameter in (mm)	Approx. Net Weight lbs/kft (kg/km)	Conduit in Air	Underground Duct
1/3 Reduced Neutral
1/0	0.362(9.2)	1.27(32.3)	9 x 14	0.050(1.3)	1.62(41.1)	1,195(1,778)	210		250
2/0	0.405(10.3)	1.31(33.3)	11 x 14	0.050(1.3)	1.66(42.2)	1,335(1,986)	235		280
3/0	0.456(11.6)	1.37(34.8)	14 x 14	0.050(1.3)	1.71(43.4)	1,515(2,254)	265		320
4/0	0.512(13.0)	1.42(36.1)	18 x 14	0.075(1.9)	1.82(46.2)	1,795(2,671)	300		360
250	0.558(14.2)	1.48(37.6)	21 x 14	0.075(1.9)	1.88(47.8)	1,995(2,969)	340		380
350	0.661(16.8)	1.58(40.1)	29 x 14	0.075(1.9)	1.98(50.3)	2,480(3,690)	400		460
500	0.789(20.0)	1.71(43.4)	26 x 12	0.075(1.9)	2.18(55.4)	3,275(4,873)	470		525
750	0.968(24.6)	1.91(48.5)	25 x 10	0.075(1.9)	2.41(61.2)	4,520(6,726)	560		590
1000	1.117(28.4)	2.06(52.3)	32 x 10	0.075(1.9)	2.56(65.0)	5,620(8,362)	620		665
Full Neutral
1/0	0.362(9.2)	1.27(32.3)	25 x 14	0.050(1.3)	1.62(41.1)	1,385(2,061)	200		245
2/0	0.405(10.3)	1.31(33.3)	32 x 14	0.050(1.3)	1.66(42.2)	1,585(2,358)	235		280
3/0	0.456(11.6)	1.37(34.8)	25 x 12	0.075(1.9)	1.80(45.7)	1,915(2,849)	265		315
4/0	0.512(13.0)	1.42(36.1)	32 x 12	0.075(1.9)	1.85(47.0)	2,225(3,311)	305		350

CERTIFICATIONS

Medium Voltage Primary Cable with full concentric neutral
