1.0mm2 V90 earth cable

PRODUCT REAL SHOT

1.0mm2 PVC building wire green yellow

Solid Copper Earth Conductor for Protected Fixed Wiring

1.0mm2 green yellow earth wire uses a 1/1.13 mm plain annealed copper core for protected fixed wiring where a firm Class 1 conductor is preferred. The Class 1 protective earth conductor is manufactured to AS/NZS 1125 and insulated with V-90 PVC under AS/NZS 5000.1. Rated 0.6/1kV, this PVC insulated earth cable has no outer sheath and is specified for a 75°C maximum continuous operating temperature. GERITEL WIRE can support green/yellow identification, project printing, measured coil lengths and clear batch labels. Final selection should be checked against the wiring rules, terminal design and fault-current requirements. Optional samples and pre-production label approval can be arranged for distributor or project orders.

PRODUCT SPECIFICATIONS

185mm2 copper conduit wire

Applications

For seperate earth conductors. For switchboard and control panel wiring. For fixed wiring within other enclosures or apparatus where the cable is not accessible without the use of tools. For use where improved aging properties to those of 75°C PVC are required because of higher ambient temperatures. Suitable for glanding

SPECIFICATIONS

CONDUCTOR

Plain annealed copper conductor to AS/NZS 1125
Maximum continuous operating temperature: 75°C

Can also be operated at temperatures up to 90°C when not exposed to mechanical deformation (see AS/NZS 3008.1)

INSULATION

V-90 PVC
Colours: Green/Yellow

Conductor
Conductor			Cable				Min. installed bending radius mm
Nominal C.S.A mm²	Nominal diameter of wires No/mm	Nominal diameter mm	Nominal insulation thickness mm	Overall diameter		Approx. mass kg/100 m
Nominal C.S.A mm²	Nominal diameter of wires No/mm	Nominal diameter mm	Nominal insulation thickness mm	Minimum mm	Maximum mm	Approx. mass kg/100 m
1.0*	1/11.3	1.13	0.8	2.6	2.8	1.7	10
1.5	7/0.50	1.5	0.8	3.0	3.2	2.2	15
2.5*	1/1.78	1.78	0.8	3.3	3.5	3.3	15
2.5	7/0.67	2.0	0.8	3.5	3.7	3.4	15
4	7/0.85	2.6	1.0	4.5	4.6	5.4	20
6	7/1.04	3.1	1.0	5.1	5.2	7.6	20
10	7/1.35	4.1	1.0	6.0	6.1	12	25
16	7/1.70	5.1	1.0	7.1	7.2	18	30
25	19/1.35	6.8	1.2	9.1	9.3	27	35
35	19/1.53	7.7	1.2	10.0	10.1	36	40
50	19/1.78	8.9	1.4	11.6	11.9	51	50
70	19/2.14	10.7	1.4	13.4	13.5	70	55
95	19/1.45	12.5	1.6	15.9	15.9	98	65
120	37/2.03	14.2	1.6	17.4	17.4	120	70
150	37/2.25	15.8	1.8	19.5	19.5	148	80
185	37/2.52	17.6	2.0	21.7	21.7	185	90

					Electrical characteristics
Conductor nominal C.S.A. mm²	Current rating (a)				Electrical characteristics
	Three phase		Single phase		Maximum D.C. resistance at20°C Ω/km	Reactance per core (Trefoil, Touching) Ω/km
	In conduit in air A	Underground in duct A	In conduitinair A	Underground in duct A	Maximum D.C. resistance at20°C Ω/km	Reactance per core (Trefoil, Touching) Ω/km
1.0*	11	16	13	18	18.1	0.119
1.5	14	20	16	24	13.6	0.111
2.5*	20	28	22	33	7.41	0.102
2.5	20	28	22	33	7.41	0.102
4	26	37	30	42	4.61	0.102
6	34	46	38	53	3.08	0.0967
10	47	61	53	71	1.83	0.0906
16	62	80	71	91	1.15	0.0861
25	87	105	97	120	0.727	0.0853
35	100	125	115	145	0.524	0.0826
50	125	150	140	170	0.387	0.0797
70	155	185	175	210	0.268	0.0770
95	185	225	210	260	0.193	0.0766
120	220	260	250	295	0.153	0.0743
150	250	290	280	335	0.124	0.0745
185	285	335	325	380	0.0991	0.0744

CERTIFICATIONS

1.0mm2 single core earth cable

1.0mm2 copper earth conductor

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Industrial Control Panel

Renewable Energy Power Connection

Switchboard Wiring

CASE

Adelaide Airport Switchboard Upgrade

Industrial Main Switchboard Power Distribution

Main Switchboard Flexible Cable Replacement

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

GLOBAL CERTIFICATIONS

1.0mm2 green yellow earth wire 500m

CUSTOMER PHOTOS

1.0mm2 earth cable supplier

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

What is V-90 insulated single core electric earth cable used for?

V-90 earth cable is used as a separate protective earthing conductor in protected fixed wiring, including switchboards, control panels, enclosures and electrical apparatus. GERITEL WIRE supplies the confirmed conductor size, green/yellow identification, project length and packing details so buyers can match the cable to approved installation drawings.

What does V90 mean on this green/yellow wire?

V90 insulated earth wire uses V-90 PVC insulation, but the product name alone should not be treated as a universal installation-temperature approval. For this GERITEL WIRE specification, use 75°C as the maximum continuous operating temperature and confirm any higher-temperature condition against the project design and current local rules.

Is this a single-core cable or a multicore cable?

This is a single core electric earth cable containing one plain annealed copper conductor with V-90 PVC insulation and no outer sheath. GERITEL WIRE identifies the product as 1C in quotations and labels, helping customers avoid confusing it with twin-and-earth, TPS, multicore or sheathed earth cable constructions.

Why is green/yellow commonly used for this product?

Green yellow building wire is commonly reserved for protective earthing identification, reducing the risk of confusing the conductor with active or neutral wiring. GERITEL WIRE can maintain the approved green/yellow colour across the order and clearly separate sizes and lengths on package labels for safer warehouse and site handling.
