1.5mm2 V90 earth cable

PRODUCT REAL SHOT

1.5mm2 PVC building wire green yellow

Class 2 Earth Wire for Conduit and Panel Installations

1.5mm2 V90 grounding wire is built with seven 0.50 mm plain annealed copper strands, giving a practical Class 2 construction for protected conduit, panel and enclosure wiring. As a single core building wire earth product, it is PVC insulated only, unsheathed and manufactured to AS/NZS 5000.1 with the conductor aligned to AS/NZS 1125. This 600/1000V earth conductor is intended for fixed installation and a maximum continuous operating temperature of 75°C. GERITEL WIRE can arrange green/yellow colour control, sequential marking, custom coil lengths and export labels. Designers should confirm earth sizing, conduit fill and terminal acceptance for the actual circuit. Sample approval can be arranged before volume production.

PRODUCT SPECIFICATIONS

1.5mm2 single core earth cable

Applications

For seperate earth conductors. For switchboard and control panel wiring. For fixed wiring within other enclosures or apparatus where the cable is not accessible without the use of tools. For use where improved aging properties to those of 75°C PVC are required because of higher ambient temperatures. Suitable for glanding

SPECIFICATIONS

CONDUCTOR

Plain annealed copper conductor to AS/NZS 1125
Maximum continuous operating temperature: 75°C

Can also be operated at temperatures up to 90°C when not exposed to mechanical deformation (see AS/NZS 3008.1)

INSULATION

V-90 PVC
Colours: Green/Yellow

Conductor
Conductor			Cable				Min. installed bending radius mm
Nominal C.S.A mm²	Nominal diameter of wires No/mm	Nominal diameter mm	Nominal insulation thickness mm	Overall diameter		Approx. mass kg/100 m
Nominal C.S.A mm²	Nominal diameter of wires No/mm	Nominal diameter mm	Nominal insulation thickness mm	Minimum mm	Maximum mm	Approx. mass kg/100 m
1.0*	1/11.3	1.13	0.8	2.6	2.8	1.7	10
1.5	7/0.50	1.5	0.8	3.0	3.2	2.2	15
2.5*	1/1.78	1.78	0.8	3.3	3.5	3.3	15
2.5	7/0.67	2.0	0.8	3.5	3.7	3.4	15
4	7/0.85	2.6	1.0	4.5	4.6	5.4	20
6	7/1.04	3.1	1.0	5.1	5.2	7.6	20
10	7/1.35	4.1	1.0	6.0	6.1	12	25
16	7/1.70	5.1	1.0	7.1	7.2	18	30
25	19/1.35	6.8	1.2	9.1	9.3	27	35
35	19/1.53	7.7	1.2	10.0	10.1	36	40
50	19/1.78	8.9	1.4	11.6	11.9	51	50
70	19/2.14	10.7	1.4	13.4	13.5	70	55
95	19/1.45	12.5	1.6	15.9	15.9	98	65
120	37/2.03	14.2	1.6	17.4	17.4	120	70
150	37/2.25	15.8	1.8	19.5	19.5	148	80
185	37/2.52	17.6	2.0	21.7	21.7	185	90

					Electrical characteristics
Conductor nominal C.S.A. mm²	Current rating (a)				Electrical characteristics
	Three phase		Single phase		Maximum D.C. resistance at20°C Ω/km	Reactance per core (Trefoil, Touching) Ω/km
	In conduit in air A	Underground in duct A	In conduitinair A	Underground in duct A	Maximum D.C. resistance at20°C Ω/km	Reactance per core (Trefoil, Touching) Ω/km
1.0*	11	16	13	18	18.1	0.119
1.5	14	20	16	24	13.6	0.111
2.5*	20	28	22	33	7.41	0.102
2.5	20	28	22	33	7.41	0.102
4	26	37	30	42	4.61	0.102
6	34	46	38	53	3.08	0.0967
10	47	61	53	71	1.83	0.0906
16	62	80	71	91	1.15	0.0861
25	87	105	97	120	0.727	0.0853
35	100	125	115	145	0.524	0.0826
50	125	150	140	170	0.387	0.0797
70	155	185	175	210	0.268	0.0770
95	185	225	210	260	0.193	0.0766
120	220	260	250	295	0.153	0.0743
150	250	290	280	335	0.124	0.0745
185	285	335	325	380	0.0991	0.0744

CERTIFICATIONS

1.5mm2 copper earth conductor

1.5mm2 protective earth conductor

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Industrial Control Panel

Renewable Energy Power Connection

Switchboard Wiring

CASE

Adelaide Airport Switchboard Upgrade

Industrial Main Switchboard Power Distribution

Main Switchboard Flexible Cable Replacement

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

GLOBAL CERTIFICATIONS

1.5mm2 earth cable supplier

CUSTOMER PHOTOS

green yellow earth wire

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

Which product standard applies to the earth cable?

AS/NZS 5000.1 earth cable is the product basis for this 0.6/1kV V-90 PVC insulated single core. GERITEL WIRE can include the agreed standard reference in the datasheet, cable printing and conformity documents, while the installer remains responsible for applying the current wiring and installation rules.

Which standard covers the copper conductor?

The AS/NZS 1125 copper conductor requirement covers the plain annealed copper construction used in this product. GERITEL WIRE can confirm the nominal size and strand arrangement for the ordered item and can align batch inspection documents with the approved conductor specification when requested before production.

What is the voltage rating of the cable?

The 0.6/1kV earth wire is rated 600/1000V. Voltage rating does not determine protective-earth size by itself; fault current, disconnection time, conductor route and local wiring rules must also be considered. GERITEL WIRE can provide the cable construction and dimensional data required for the engineer's review.

Does the cable have a separate outer jacket?

PVC insulated only earth cable has V-90 PVC around the copper conductor but no additional outer sheath. It should therefore be installed using a protected wiring method suitable for the environment. GERITEL WIRE states the insulation-only construction clearly in quotations to prevent substitution for SDI, TPS or direct-burial cable.
