- Conductors:14AWG-750 MCM fully annealed stranded bare copper per ASTM B3. Class B Stranding per ASTM B 8.
- Insulation: Chemically cross-linked polyethylene
- Colors: Black, Brown, Orange, Yellow, Green, White, Red, Gray, Blue.
Application
IMSA street lighting cable is mainly used in municipal projects such as urban street lighting, traffic signal systems, highway lighting, square and park landscape lighting, and is also suitable for outdoor power distribution in commercial buildings, industrial plants and residential areas. Its weather resistance and flame retardant design enable it to operate stably in harsh environments, ensuring safe and reliable power supply for public facilities. In addition, its excellent electrical performance and mechanical strength also make it an ideal choice for lighting and power distribution systems that require long-term durability and low maintenance.
Feature
IMSA street lighting cable is a single conductor rated for 90°C in both wet and dry conditions, insulated with high-performance chemically cross-linked polyethylene (XLPE) for enhanced durability and thermal resistance. Designed for superior flame retardance, it is ideal for general-purpose wiring in street lighting, traffic signals, and outdoor illumination systems, as well as residential, commercial, and industrial power distribution.
Certification
IMSA street lighting cable is UL certified and has passed a number of rigorous tests in terms of electrical performance, flame retardancy, heat resistance, and mechanical strength. It complies with relevant UL standards (such as UL 44, UL 83, etc.), ensuring that it can maintain stable operation in short circuits, overloads, and harsh environments, reducing the risk of fire and electrical accidents.
Package
Production Line
Dongguan Greater Wire & Cable Co., Ltd. was established in 1995, it is a professional wire and cable manufacturer. Our company has advanced production equipment and production technology, complete testing equipment, and strong product technology strength. After years of hard work and the support of clients from all over the World, our company has developed rapidly and won a high honor and share in overseas markets. The company has passed the ls09001 quality management system certification, National high tech enterprise certification, national specialization, and special new enterprise certification.
customer
Partner
FAQ
Q: Where is your factory?
Q: What payment methods are accepted for purchasing wires and cables?
Hot Tags: 600v xlpe use-2/rhh/rhw-2 imsa street lighting cable, China 600v xlpe use-2/rhh/rhw-2 imsa street lighting cable manufacturers, suppliers, factory, 0 6 1KV Single Core Building Cable, tuv solar cable, h05vv-f, SAA Orange Circular Cable, HO7Z K 90 LSOH, rubber cable
| Conductor | Insulation Thickness (mils) | Nominal 0.D.(mils) | Approx.Net Wt.Per 1000'(lbs.) | Allowable Ampacities+ | |||
| Size (AWG or kcmil) | No.of strands | 60℃ | 75℃ | 90℃ | |||
| 14* | 7 | 30 | 130 | 24 | 15 | 15 | 15 |
| 12* | 1 | 30 | 141 | 18 | 20 | 20 | 20 |
| 10* | 1 | 30 | 147 | 26 | 30 | 30 | 30 |
| 12* | 7 | 30 | 162 | 37 | 15 | 15 | 15 |
| 10* | 7 | 30 | 171 | 40 | 20 | 20 | 20 |
| 8 | 7 | 45 | 232 | 65 | 30 | 30 | 30 |
| 6 | 7 | 45 | 268 | 96 | 40 | 50 | 55 |
| 4 | 7 | 45 | 311 | 147 | 55 | 65 | 75 |
| 3 | 7 | 45 | 337 | 183 | 70 | 85 | 100 |
| 2 | 7 | 45 | 367 | 227 | 85 | 100 | 115 |
| 1 | 19 | 55 | 435 | 291 | 95 | 115 | 130 |
| 1/0 | 19 | 55 | 477 | 363 | 110 | 130 | 145 |
| 2/0 | 19 | 55 | 521 | 453 | 125 | 150 | 170 |
| 3/0 | 19 | 55 | 571 | 565 | 145 | 175 | 195 |
| 4/0 | 19 | 55 | 627 | 706 | 165 | 200 | 225 |
| 250 | 37 | 65 | 695 | 835 | 195 | 230 | 260 |
| 300 | 37 | 65 | 748 | 995 | 215 | 255 | 290 |
| 350 | 37 | 65 | 798 | 1155 | 240 | 285 | 320 |
| 400 | 37 | 65 | 843 | 1314 | 260 | 310 | 350 |
| 500 | 37 | 65 | 927 | 1633 | 280 | 335 | 380 |
| 600 | 61 | 80 | 1033 | 1965 | 320 | 380 | 430 |
| 750 | 61 | 80 | 1102 | 2282 | 350 | 420 | 475 |
| 1000 | 61 | 80 | 1284 | 3229 | 455 | 545 | 615 |
