Name: China A Flexible Packaging Machine Silicone Cable For Heated Production Lines Manufacturers Suppliers Factory
Brand: GERITEL
SKU: 313956067

Description

Technical Parameters

Certification

reliable silicone multicore cable

PRODUCT REAL SHOT

reliable high temperature silicone cable

reliable industrial silicone cable

Heat Sealing Machine Cable for Heaters, Sensors and Control Modules

Automated packaging lines combine heater bars, sealing jaws, sensors, motors and compact control cabinets, so cable routing must tolerate local heat without becoming difficult to install. GERITEL WIRE supplies a thermoforming machine cable based on flexible tinned copper conductors, silicone insulation and a silicone sheath for fixed or occasionally moved connections. As a silicone control cable for packaging line equipment, it can be considered for heat-sealing, shrink-wrapping, laminating and film-processing machinery where tensile stress is limited. Machine builders can specify identification, jacket colour, printing, reels or cut lengths to suit assembly flow.

PRODUCT SPECIFICATIONS

reliable flexible silicone cable

Applications

This cable is used for connection of electrical appliances without mechanical stress at increased environmental temperatures, for example in steelworks, but also at low temperatures. Insulation and sheath are resistant to most oils,acids, lyes and oxidants.

SPECIFICATIONS
Voltage Rating Uo/U	300/500V
Temperature Rating	Fixed:-60°C to +200°C
Minimum Bending Radius	Fixed: 5 x overall diameter Flexed: 15 x overall diameter
Conductor	Class 5 flexible Stranded Tinned Copper
Insulation	Silicone rubber
Outer Sheath	Silicone Rubber
Core ldentification	3 cores: Green/Yellow,Blue,Brown 4cores: Green/Yellow,Blue,Black,Grey 5cores: Green/Yellow,Blue,Brown,Black,Grey More than 5 cores: Black numebered +Green/Yellow
Sheath Colour	Red,Black

DIMENSIONS

NO. OF CORES
NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
3	0.75	6.8	66
3	1	7.4	78
3	1.5	8	98
3	2.5	9.7	152
3	4	11.5	249
3	6	14.2	352
4	0.75	7.8	84
4	1	8	95
4	1.5	8.8	122
4	2.5	10.6	189
4	4	13	330
4	6	16.2	429
4	10	21.4	710
4	16	24	1014
4	25	29.3	1460
4	35	33	2044
4	50	34	2990
5	0.75	8.5	101
5	1	8.8	116
5	1.50	9.6	148
5	2.5	11.6	229
5	4	15	359
5	6	17.7	564
5	10	22.5	900
5	16	26.9	1206
5	35	36.7	2850
7	0.75	9.6	158
7	1	10	177
7	1.5	10.9	232
7	2.5	13.2	348
7	4	16.2	487
7	6	19.3	685
12	0.75	11.1	178
12	1.5	14.8	332
12	2.5	18	530
18	0.75	13.3	260
18	1.5	17.6	510
24	1.5	20.2	635
25	0.75	15.6	370

CERTIFICATIONS

high flexibility SiHF-J silicone cable

PACKAGING

Roll

high flexibility silicone multicore cable

Plastic Reel

Small Wooden Reel

APPLICATION

high flexibility high temperature silicone cable

HVAC & Refrigeration Systems

Industrial Automation & Machinery

Industrial Control Cabinet Wiring

CASE

Northern Steel High-Temperature Control Upgrade Project

OceanStar Marine Electrical Retrofit Project

PolarFresh Industrial Refrigeration Expansion Project

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

high temperature cable for hot rolling mills

silicone control cable for hot rolling mills

GLOBAL CERTIFICATIONS

cold rolling mill control systems silicone cable

CUSTOMER PHOTOS

SiHF-J cable for cold rolling mill control systems

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

high temperature cable for cold rolling mill control systems

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

silicone control cable for cold rolling mill control systems

SiHF-J cable for metal smelting equipment

silicone control cable for metal smelting equipment

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

Is SiHF-J suitable near furnace burners?

A furnace connection cable can serve burner controls, fans, sensors and heater auxiliaries when it is kept away from direct flame, crushing and excessive radiant heat. GERITEL WIRE asks for the cable-route temperature rather than furnace chamber temperature and can recommend protective routing or a different construction when exposure is too severe.

Can the cable be used in freezers and cold rooms?

A cold storage silicone cable is useful for heaters, evaporator fans, defrost controls and equipment wiring because silicone remains flexible at low temperature. GERITEL WIRE checks condensation, gland sealing, movement during service and local electrical requirements; it is not positioned as a submersible or direct-burial product.

Does the temperature rating include conductor heating from current?

The rating of a high temperature equipment cable must account for both ambient heat and temperature rise caused by current. GERITEL WIRE requests load current, grouping, ventilation and duty cycle so the selected conductor is not sized from ambient temperature alone. Final ampacity should follow the project engineer and applicable installation rules.

Can the sheath touch a 200°C metal surface?

A silicone cable for hot surfaces should not be approved only from a headline temperature. Continuous contact can create local hot spots, abrasion and mechanical damage. GERITEL WIRE recommends measuring the contact temperature, using supports or thermal separation where possible, and confirming the exact ordered construction before installation.
