Heat Pump Internal Wiring for Localized Thermal Exposure

Air handling unit heat wire can connect crankcase heaters, electric reheats, sensors and controls within protected equipment compartments. An HVAC heater connection cable with silicone insulation helps where localized component temperature or cold-weather flexibility exceeds ordinary wiring capability. GERITEL WIRE provides options for heat-pump manufacturers, packaged-unit OEMs and controls integrators. Temperature resistant HVAC wire should be routed clear of fans, condensate paths and service panels, with secure supports and compatible terminals. Check refrigerant and oil exposure, enclosure conditions, current loading, vibration and the product safety standard; outdoor UV or weather resistance must be separately documented for the exact cable.

PRODUCT SPECIFICATIONS

best silicone wire for water heaters

Applications

Designed for use in environments where sustained heat resistance is required, SIA and SIAF cables have heat resistant properties up to 200°C and can also be employed at temperatures as low as -60°C. These cables are low smoke zero halogen and are suitable for power plants, a wide range of industrial applications in processing, packaging, refrigeration,foundaries, air craft construction and ship building.

SPECIFICATIONS
Voltage Rating Uo/U	SIA:300/500V SIAF:0.25mm² to 6mm² 300/500V ; 10mm² and above: 0.6/1kV
Temperature Rating	Fixed:-60°C to +200°C
Minimum Bending Radius	Fixed: 4 x overall diameter
Conductor	Class 1 solid copper (plain or tinned) conductor Class 5 flexible copper (plain or tinned) conductor
Insulation	Silicone rubber
Sheath Colour	Black,Blue,Brown,Red ,White,Grey,Pink,Yellow,Green/Yellow,Orange,Violet
Standards	EN 50525-2-41, IEC/EN 60228

DIMENSIONS

Solid Core Silicone Rubber Insulated Cable (SIA)

NO.OF CORES

	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL THICKNESS OF INSULATION mm²	NOMINAL OVERALL DIAMETER mm²	NOMINAL WEIGHT kg/km
	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL THICKNESS OF INSULATION mm²	NOMINAL OVERALL DIAMETER mm²	NOMINAL WEIGHT kg/km
1	0.5	0.6	2.0	10
1	0.75	0.6	2.2	12
1	1	0.6	2.3	15
1	1.5	0.6	2.6	20
1	2.5	0.7	3.2	31
1	4	0.8	3.9	48
1	6	0.8	4.4	67
1	10	1	5.6	108

Flexible Core Silicone Rubber Insulated Cable (SIAF)

NO.OF CORES

	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL THICKNESS OF INSULATION mm²	NOMINAL OVERALL DIAMETER mm²	NOMINAL WEIGHT kg/km
	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL THICKNESS OF INSULATION mm²	NOMINAL OVERALL DIAMETER mm²	NOMINAL WEIGHT kg/km
1	0.25	0.6	1.8	7
1	0.35	0.6	1.9	8
1	0.5	0.6	2.1	10
1	0.75	0.6	2.3	13
1	1	0.6	2.5	15
1	1.5	0.6	2.8	21
1	2.5	0.7	3.5	34
1	4	0.8	4.1	49
1	6	0.8	4.7	68
1	10	1	6.1	110
1	16	1.2	7.5	168
1	25	1.4	9.1	254
1	35	1.4	10.3	347
1	50	1.6	12	490
1	70	1.8	13.7	686
1	95	1.8	15.6	888
1	120	1.8	17.4	1149
1	150	2	19.3	1411
1	185	2.2	21.4	1722
1	240	2.4	24.3	2284
1	300	2.6	26.9	2895

CONDUCTORS

Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables

NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM RESISTANCE OF CONDUCTOR AT 20°C ohms/km
NOMINAL CROSS SECTIONAL AREA mm²	Circular, Annealed Copper Conductors, Metal-Coated Wires
0.5	36.7
0.75	24.8
1	18.2
1.5	12.2
2.5	7.56
4	4.7
6	3.11
10	1.84

Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables (SIAF)

NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM DIAMETER OF WIRES IN CONDUCTOR mm	MAXIMUM RESISTANCE OF CONDUCTOR AT 20°C ohms/km
NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM DIAMETER OF WIRES IN CONDUCTOR mm	Metal-Coated Wires
0.25	0.21	86
0.35	0.21	55.5
0.5	0.21	40.1
0.75	0.21	26.7
1	0.21	20
1.5	0.26	13.7
2.5	0.26	8.21
4	0.31	5.09
6	0.31	3.39
10	0.41	1.95
16	0.41	1.24
25	0.41	0.795
35	0.41	0.565
50	0.41	0.393
70	0.51	0.277
95	0.51	0.21
120	0.51	0.164
150	0.51	0.132
185	0.51	0.108
240	0.51	0.0817
300	0.51	0.0654

CURRENT CARRYING CAPACITY

Solid Core Silicone Rubber Insulated Cable (SIA)

NOMINAL CROSSS ECTIONAL AREA mm²	CURRENT RATING IN AIR Amps
NOMINAL CROSSS ECTIONAL AREA mm²	at 30°C	at 60°C	at 90°C	at 120°C	at 150°C
0.5	24	21	17	14	9
0.75	30	26	22	17	11
1	36	31	26	20	13
1.5	45	39	33	26	17
2.5	61	53	45	55	23
4	81	71	60	47	31
6	105	92	77	60	39
10	146	128	107	84	55

Flexible Core Silicone Rubber Insulated Cable (SIAF)

NOMINAL CROSSS ECTIONAL AREA mm²	CURRENT RATING IN AIR Amps
NOMINAL CROSSS ECTIONAL AREA mm²	at 30°C	at 60°C	at 90°C	at 120°C	at 150°C	at 170°C
0.25	15	13	11	9	6	3
0.35	19	17	14	11	7	4
0.5	23	20	17	13	9	5
0.75	30	26	22	17	11	6
1	35	31	26	20	13	7
1.5	44	38	32	25	17	8
2.5	61	53	45	35	23	12
4	82	71	60	47	31	16
6	104	91	77	60	39	20
10	148	129	108	85	56	28
16	197	173	145	114	75	58
25	263	230	193	151	99	51
35	327	286	240	188	124	63
50	413	362	304	238	157	80
70	531	465	391	306	201	103
95	623	545	458	359	236	121
120	738	645	543	425	280	143
150	850	744	626	491	323	166
185	969	848	714	560	369	190
240	1191	1043	879	689	454	234
300	1339	1173	988	776	512	264
