- 3×Conductors: Flexible stranded tinned annealed copper conductor.
- Insulation: EPR.
- Insulation Screen: Semiconductive elastomer.
- Composite Screen (earth conductor): Tinned annealed copper braiding interwove with polyester yarn.
- Cradle Separator: Semiconductive PCP.
- 1×Central Extensible Pilot: EPR covered flexible stranded tinned copper conductor.
- Sheath: Heavy duty PCP sheath. Heavy duty CPE/CSP sheath can be offered upon request.
- Standards:
AS/NZS 1802:2003
AS/NZS 1125
AS/NZS 3808
AS/NZS 5000.1
Application
Coal mining industry power cable can be used for mine hoists. Underground hoists are one of the key equipment in mines, mainly used to transport miners, equipment and ore vertically between underground and the ground. These hoists require a lot of power support to operate efficiently and safely. The cable uses its powerful power transmission capacity to ensure that the motor of the hoist can start smoothly and continue to operate, carrying the high load requirements of transportation tasks in the mine.
Feature
Coal mining industry power cable uses flexible multi-strand tinned annealed copper conductors and EPR (ethylene propylene rubber) as insulation material. EPR has good heat resistance, corona resistance, oxidation resistance and corrosion resistance, and is suitable for long-term use in high temperature and humid mine environments. The cable uses semi-conductive elastomer as the insulation shielding layer, which effectively reduces electromagnetic interference and ensures the stability of power transmission, especially providing additional protection under high voltage conditions.
Certification
Coal mining industry power cable has passed SAA certification (safety certification for Australia and New Zealand), and the fire resistance of mining cables has been strictly verified to ensure its safety and reliability in harsh environments. Certified mining cables meet a series of standards for fire resistance, mainly including fire prevention, high temperature resistance, flame retardant, and low smoke and halogen-free performance. It can provide reliable power support in fire, overheating and high temperature environments.
Package
Company Introduction
Greater Wire Manufacturer has a professional sales team. In addition to pre-sales and after-sales services, the company attaches great importance to customer feedback and regards it as a key basis for quality improvement. Through customer feedback, the factory can understand the performance of the product in actual use, find problems in time, and make improvements. The factory also conducts customer satisfaction surveys regularly to collect information on product quality, delivery speed, service, etc. Based on these feedbacks, the factory can continuously optimize product design and production processes to enhance customer experience.
customer
Partner
FAQ
Q: What is the fire resistance of mining cables?
Q: Are mining cables explosion-proof?
Hot Tags: as/nzs 1802 type 210 1.1/1.1kv coal mining industry power cable, China as/nzs 1802 type 210 1.1/1.1kv coal mining industry power cable manufacturers, suppliers, factory, xlpe power cable, single core building cable, CUL Standard XLPE Copper RW75 RW9O RWU75 RWU90 Cable, USE 2 XHHW XHHW 2 XLPE Insulation Copper Wire, HO7V-U, HO5V-K
|
Nominal
Conductor
Area
|
Strand Size
|
Insulation
Thickness
|
Core Screen
|
Pilot Conductor
|
Thickness
of Sheath
|
Nominal
Overall
Diameter
|
Nominal
Weight
|
||
|
Strand Size
|
Area of
Screen
|
Strand Size
|
Thickness
of Covering
|
||||||
|
mm²
|
No/mm
|
mm
|
No/mm
|
mm²
|
No/mm
|
mm
|
mm
|
mm
|
kg/100m
|
|
Type 210
|
|||||||||
| 1.5 | 30/0.25 | 1.4 | 7/0.25 | 5.2 | 24/0.20 | 0.8 | 3.0 | 23.7 | 83 |
| 2.5 | 50/0.25 | 1.5 | 7/0.25 | 5.8 | 24/0.20 | 0.8 | 3.0 | 25.1 | 92 |
