1.5mm yellow TPS cable

PRODUCT REAL SHOT

1.5mm 3 core and earth cable

1.5 mm² Yellow Flat TPS Cable for Capsule Houses and Hotels

The 1.5mm Yellow Twin and Earth Cable is designed for protected fixed wiring in residential and light-commercial lighting circuits that require active, neutral and protective earth conductors. GERITEL WIRE uses plain annealed copper, V-90 PVC insulation and a yellow flat sheath for clear project identification. This Yellow Residential Lighting Cable can serve bedrooms, corridors, staircases and hotel pods when the design permits. For modular hospitality projects, Yellow TPS Cable for Capsule House Lighting offers compact routing inside protected wall and ceiling zones. Samples, OEM printing and 100m packaging are available for 1.5 mm² Yellow Flat Building Cable; installers must confirm load and local compliance.

PRODUCT SPECIFICATIONS

1.5mm² yellow flat TPS cable

Applications

For general wiring, unenclosed, enclosed in conduit,for domestic, commercial and industrial installations where not subject to mechanical damage.

SPECIFICATIONS
Cable description	PVC insulated laid flat and PVC sheathed cableto AS/NZS 5000.2
Approvals	AS/NZS 5000.2
Behaviour in flame and fire	Flame retardant
Temperature range	Normal operating temperature: +90°C Minimum operating temperature: 0°C
Flexibility	Semi-rigid
Resistance to	Chemical exposure: Occasional Mechanical impact: Light Water exposure:Occasional condensation Solar radiation and weather exposure:Occasional
Cable design	Conductor: Plain annealed copper conductor to AS/NZS 1125 Can also be operated at temperatures up to 90°C when not exposed to mechanical deformation(see AS/NZS 3008.1). Insulation: V-90 PVC Colours: Red, Black, Green/Yellow Sheath: 3V-90 PVC Colour: Yellow
Installation conditions	In free air In conduit In ground with protection In duct External building with protection

	Conductor
Insulation Colours	Conductor			Cable						Min. installed bending radius(a) mm
	Nominal C.S.A mm²	Nominal diameter of wires No/mm	Nominal diameter mm	Nominal insulation thickness mm	Overall diameter mm				Approx. mass kg/100m
					Minimum		Maximum
					Major axis	Major axis	Major axis	Major axis
2C+E FLAT PVC
Red,Green/Yellow,Black	1.0	7/0.42	1.26	0.6	9.5	4.3	9.6	4.4	8	20
Red,Green/Yellow,Black	1.5	7/0.50	1.56	0.6	9.8	4.5	10.1	4.6	10	20
Red,Green/Yellow,Black	2.5	7/0.67	2.0	0.7	12.1	5.4	12.4	5.5	15	20
Red,Green/Yellow,Black	4	7/0.85	2.6	0.8	13.8	6.3	14.1	6.5	19	30
Red,Green/Yellow,Black	6	7/1.04	3.1	0.8	14.9	6.9	15.3	7.1	24	30
Red,Green/Yellow,Black	10	7/1.35	4.1	1	18.9	8.4	19.6	8.8	38	35
Red,Green/Yellow,Black	16	7/1.70	5.1	1	21.8	9.7	22.5	10.0	54	40
3C+E FLAT PVC
Red,White,Green/Yellow,Black	1.0	7/0.42	1.26	0.6	11.4	4.5	11.7	4.6	10	20
Red,White,Green/Yellow,Black	1.5	7/0.50	1.56	0.6	12.4	4.5	12.8	4.6	12	20
Red,White,Green/Yellow,Black	2.5	7/0.67	2.0	0.7	15..4	5.4	15.8	5.5	19	20
Red,White,Green/Yellow,Black	4	7/0.85	2.6	0.8	17.9	6.3	18.3	6.5	26	25
Red,White,Green/Yellow,Black	6	7/1.04	3.1	0.8	19.5	6.9	20.1	7.1	33	30
Red,White,Green/Yellow,Black	10	7/1.35	4.1	1.0	24.9	8.4	25.8	8.8	52	35
Red,White,Green/Yellow,Black	16	7/1.70	5.1	1.0	28.8	9.7	29.7	10.0	75	40
3C FLAT PVC
Red, White, Blue	1.0	7/0.42	1.26	0.6	8.8	4.1	9.0	4.3	8	20
Red, White, Blue	1.5	7/0.50	1.56	0.6	9.8	4.5	10.1	4.6	10	20
Red, White, Blue	2.5	7/0.67	2.0	0.7	12.1	5.4	12.4	5.5	15	20

CERTIFICATIONS

1.5 mm2 yellow sheath electrical cable

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Capsule Accommodation

Prefabricated Housing

Recreational Vehicle Wiring

CASE

2020 Ford Transit AWD Camper Van Conversion

Epping Forest District Council Modular Homes

Wethersfield Modular Accommodation Deployment

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

1.5 mm2 yellow electrical cable wholesale

GLOBAL CERTIFICATIONS

1.5mm² yellow cable datasheet

CUSTOMER PHOTOS

3V-90 yellow flat cable

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

What do the red, black and green/yellow cores mean?

Core colours help identify circuit conductors, but installers must follow the applicable wiring rules and project drawings. The GERITEL Red Black Earth TPS Cable commonly uses red and black insulated working conductors with a green/yellow protective earth. We can customize approved printing on the Yellow Sheath Electrical Cable while keeping the agreed internal structure unchanged.

Is this cable round or flat?

It is a Yellow Flat TPS Cable, designed with the conductors arranged in a flat profile rather than a circular bundle. This format is commonly selected for protected routing through walls, ceilings and building cavities. GERITEL WIRE can supply dimensional data for each Flat Twin and Earth Cable size so buyers can check conduit, clip and gland compatibility.

What does TPS mean in electrical cable terminology?

TPS commonly refers to thermoplastic-sheathed cable. In this product, PVC insulation and a PVC outer sheath form a Thermoplastic Sheathed Cable intended for fixed wiring. The flat 2C+E version can also be searched as Yellow PVC Flat Cable. GERITEL WIRE supplies technical data so customers do not confuse electrical TPS with unrelated uses of the abbreviation.

Is the yellow sheath only for identification?

The yellow colour mainly helps distinguish the cable during installation and maintenance; it does not by itself prove the core count, voltage rating or application. Buyers should confirm the printing and datasheet for any Yellow Sheath TPS Cable. GERITEL WIRE can mark the agreed voltage, standard and size on the Yellow Fixed Wiring Cable for easier project identification.
