Name: China 1mm Yellow 2 Core And Earth Flat TPS Lighting Cable Manufacturers Suppliers Factory
Brand: GERITEL
SKU: 310374479

Description

Technical Parameters

Certification

1mm yellow TPS cable

PRODUCT REAL SHOT

1.5mm 3 core and earth cable

1.0 mm² Yellow Twin and Earth Cable for Modular Lighting

GERITEL WIRE supplies 1mm Yellow 2 Core and Earth Cable for protected fixed lighting and switching circuits requiring two working conductors plus earth. Plain annealed copper, V-90 PVC insulation and a yellow flat sheath support compact routing through walls, ceilings and factory-built modules. The Yellow Flat TPS Lighting Cable can serve prefabricated homes, capsule accommodation and selected container-room lighting when the circuit design permits. It also targets Yellow TPS Cable for Modular House Lighting. Samples, custom printing and project packaging are available for 1.0 mm² Yellow Twin and Earth Cable; final use and approval scope must follow project documents and local rules.

PRODUCT SPECIFICATIONS

1mm² yellow flat TPS cable

Applications

For general wiring, unenclosed, enclosed in conduit,for domestic, commercial and industrial installations where not subject to mechanical damage.

SPECIFICATIONS
Cable description	PVC insulated laid flat and PVC sheathed cableto AS/NZS 5000.2
Approvals	AS/NZS 5000.2
Behaviour in flame and fire	Flame retardant
Temperature range	Normal operating temperature: +90°C Minimum operating temperature: 0°C
Flexibility	Semi-rigid
Resistance to	Chemical exposure: Occasional Mechanical impact: Light Water exposure:Occasional condensation Solar radiation and weather exposure:Occasional
Cable design	Conductor: Plain annealed copper conductor to AS/NZS 1125 Can also be operated at temperatures up to 90°C when not exposed to mechanical deformation(see AS/NZS 3008.1). Insulation: V-90 PVC Colours: Red, Black, Green/Yellow Sheath: 3V-90 PVC Colour: Yellow
Installation conditions	In free air In conduit In ground with protection In duct External building with protection

	Conductor
Insulation Colours	Conductor			Cable						Min. installed bending radius(a) mm
	Nominal C.S.A mm²	Nominal diameter of wires No/mm	Nominal diameter mm	Nominal insulation thickness mm	Overall diameter mm				Approx. mass kg/100m
					Minimum		Maximum
					Major axis	Major axis	Major axis	Major axis
2C+E FLAT PVC
Red,Green/Yellow,Black	1.0	7/0.42	1.26	0.6	9.5	4.3	9.6	4.4	8	20
Red,Green/Yellow,Black	1.5	7/0.50	1.56	0.6	9.8	4.5	10.1	4.6	10	20
Red,Green/Yellow,Black	2.5	7/0.67	2.0	0.7	12.1	5.4	12.4	5.5	15	20
Red,Green/Yellow,Black	4	7/0.85	2.6	0.8	13.8	6.3	14.1	6.5	19	30
Red,Green/Yellow,Black	6	7/1.04	3.1	0.8	14.9	6.9	15.3	7.1	24	30
Red,Green/Yellow,Black	10	7/1.35	4.1	1	18.9	8.4	19.6	8.8	38	35
Red,Green/Yellow,Black	16	7/1.70	5.1	1	21.8	9.7	22.5	10.0	54	40
3C+E FLAT PVC
Red,White,Green/Yellow,Black	1.0	7/0.42	1.26	0.6	11.4	4.5	11.7	4.6	10	20
Red,White,Green/Yellow,Black	1.5	7/0.50	1.56	0.6	12.4	4.5	12.8	4.6	12	20
Red,White,Green/Yellow,Black	2.5	7/0.67	2.0	0.7	15..4	5.4	15.8	5.5	19	20
Red,White,Green/Yellow,Black	4	7/0.85	2.6	0.8	17.9	6.3	18.3	6.5	26	25
Red,White,Green/Yellow,Black	6	7/1.04	3.1	0.8	19.5	6.9	20.1	7.1	33	30
Red,White,Green/Yellow,Black	10	7/1.35	4.1	1.0	24.9	8.4	25.8	8.8	52	35
Red,White,Green/Yellow,Black	16	7/1.70	5.1	1.0	28.8	9.7	29.7	10.0	75	40
3C FLAT PVC
Red, White, Blue	1.0	7/0.42	1.26	0.6	8.8	4.1	9.0	4.3	8	20
Red, White, Blue	1.5	7/0.50	1.56	0.6	9.8	4.5	10.1	4.6	10	20
Red, White, Blue	2.5	7/0.67	2.0	0.7	12.1	5.4	12.4	5.5	15	20

CERTIFICATIONS

1.5 mm² 3C+E TPS cable

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Capsule Accommodation

Prefabricated Housing

Recreational Vehicle Wiring

CASE

2020 Ford Transit AWD Camper Van Conversion

Epping Forest District Council Modular Homes

Wethersfield Modular Accommodation Deployment

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

GLOBAL CERTIFICATIONS

1mm yellow cable 100m roll

CUSTOMER PHOTOS

1mm² yellow cable datasheet

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

What is Yellow Flat TPS Cable?

Yellow Flat TPS Cable is a flat PVC-sheathed cable intended for protected fixed wiring. The GERITEL WIRE product discussed here uses two insulated working conductors plus a green/yellow protective earth conductor, so it is positioned as Yellow 2 Core and Earth Cable. We can provide construction drawings, size data and samples so buyers can confirm the exact core arrangement before ordering.

Is yellow TPS the same as twin and earth cable?

For the GERITEL WIRE structure shown, yes: it may be marketed as Yellow Twin and Earth Cable because it contains two working conductors and one protective earth conductor inside a flat sheath. However, some overseas yellow products are three-core lighting cables without earth, so buyers should verify the drawing and markings before treating every Yellow TPS Cable as twin and earth.

How many conductors are inside the GERITEL yellow TPS cable?

The illustrated GERITEL product contains two insulated working conductors plus one green/yellow earth conductor. This makes it a 2C+E Flat TPS Cable, not a three-working-core SWITCH cable. Before production, GERITEL WIRE can confirm conductor colours, earth size and overall dimensions for each Yellow Flat Building Cable specification.

Does yellow 2C+E cable include a protective earth conductor?

Yes. A genuine Yellow 2 Core and Earth Cable includes a dedicated green/yellow protective earth conductor in addition to the two working conductors. The earth conductor size may differ from the phase conductor size on some larger constructions, so GERITEL WIRE provides a size table and sample for each Yellow Twin Earth Cable order.

Hot Tags: 1mm yellow 2 core and earth flat tps lighting cable, China 1mm yellow 2 core and earth flat tps lighting cable manufacturers, suppliers, factory, 3 Core TPS Cable, SAA Australia Flat 2C E Electrical TPS Cable, SAA Australia Flat Twin Active TPS Cable, tps cable
