SiHF-J 3G0.75 silicone cable

PRODUCT REAL SHOT

high temperature cable selection guide

How SiHF-J 0.75mm² flexible silicone cable supports multi-function heater controls with neutral and earth

heater-control OEMs and appliance engineers can specify the 0.75mm high temperature power cable when ordinary PVC may harden near multi-function heater controls with neutral and earth. Fine-stranded tinned copper, silicone core insulation and a silicone jacket support flexible termination near hot equipment. The 0.75mm² conductors are positioned for low-current switching, indication and interlock functions, with three phases, neutral and protective earth in one cable. Determine current for the 0.75mm² high temperature cable for heater control panels from loaded cores, ambient heat, bundling, route and voltage drop. GERITEL WIRE can coordinate markings, reel lengths, packing and pre-order technical confirmation.

PRODUCT SPECIFICATIONS

3G0.75 Class 5 tinned copper silicone cable

Applications

This cable is used for connection of electrical appliances without mechanical stress at increased environmental temperatures, for example in steelworks, but also at low temperatures. Insulation and sheath are resistant to most oils,acids, lyes and oxidants.

SPECIFICATIONS
Voltage Rating Uo/U	300/500V
Temperature Rating	Fixed:-60°C to +200°C
Minimum Bending Radius	Fixed: 5 x overall diameter Flexed: 15 x overall diameter
Conductor	Class 5 flexible Stranded Tinned Copper
Insulation	Silicone rubber
Outer Sheath	Silicone Rubber
Core ldentification	3 cores: Green/Yellow,Blue,Brown 4cores: Green/Yellow,Blue,Black,Grey 5cores: Green/Yellow,Blue,Brown,Black,Grey More than 5 cores: Black numebered +Green/Yellow
Sheath Colour	Red,Black

DIMENSIONS

NO. OF CORES
NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
3	0.75	6.8	66
3	1	7.4	78
3	1.5	8	98
3	2.5	9.7	152
3	4	11.5	249
3	6	14.2	352
4	0.75	7.8	84
4	1	8	95
4	1.5	8.8	122
4	2.5	10.6	189
4	4	13	330
4	6	16.2	429
4	10	21.4	710
4	16	24	1014
4	25	29.3	1460
4	35	33	2044
4	50	34	2990
5	0.75	8.5	101
5	1	8.8	116
5	1.50	9.6	148
5	2.5	11.6	229
5	4	15	359
5	6	17.7	564
5	10	22.5	900
5	16	26.9	1206
5	35	36.7	2850
7	0.75	9.6	158
7	1	10	177
7	1.5	10.9	232
7	2.5	13.2	348
7	4	16.2	487
7	6	19.3	685
12	0.75	11.1	178
12	1.5	14.8	332
12	2.5	18	530
18	0.75	13.3	260
18	1.5	17.6	510
24	1.5	20.2	635
25	0.75	15.6	370

CERTIFICATIONS

3 conductor 0.75 sq mm SiHF-J control cable

PACKAGING

3G0.75 temperature sensor connection cable

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

HVAC & Refrigeration Systems

Industrial Automation & Machinery

Industrial Control Cabinet Wiring

CASE

Northern Steel High-Temperature Control Upgrade Project

4G0.75 Class 5 tinned copper silicone cable

OceanStar Marine Electrical Retrofit Project

4 conductor 0.75 sq mm SiHF-J control cable

PolarFresh Industrial Refrigeration Expansion Project

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

GLOBAL CERTIFICATIONS

5G0.75 Class 5 tinned copper silicone cable

CUSTOMER PHOTOS

5 conductor 0.75 sq mm SiHF-J control cable

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

7G0.75 Class 5 tinned copper silicone cable

7 conductor 0.75 sq mm SiHF-J control cable

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

Can standard SiHF-J be connected directly between a VFD and motor?

Do not assume standard unshielded SiHF-J is the correct VFD motor silicone cable. A drive output may require defined voltage capability, low-capacitance insulation, symmetrical earth conductors and an EMC screen to manage dv/dt and common-mode current. GERITEL WIRE can review the drive voltage, motor power, route and EMC plan, then confirm whether a screened high-temperature design is required.

May heater power and sensor signals share one SiHF-J multicore cable?

A mixed power and signal silicone cable can suffer interference, and local rules may require separation between voltage levels or safety circuits. Standard SiHF-J has no individually screened pairs, so combining heater conductors with low-level sensors should not be assumed acceptable. GERITEL WIRE can review the core schedule and recommend separate cables or a screened construction when noise immunity is important.

Can SiHF-J replace thermocouple extension wire in a hot machine?

Buyers considering SiHF-J for thermocouple circuits should note that ordinary tinned-copper cores do not replace the matching or compensating alloys required by a thermocouple type. Using the wrong conductor can introduce measurement error. GERITEL WIRE can check the instrument schedule and separate heater/control wiring from the specified thermocouple extension cable before quotation.

Is SiHF-J suitable for PT100 or other RTD sensor leads?

An RTD sensor silicone cable may use copper conductors because an RTD measures resistance, but lead resistance, two/three/four-wire configuration, noise and required accuracy still matter. Standard SiHF-J is unscreened. GERITEL WIRE can review the PT100 wiring method, conductor length and nearby power circuits, then confirm whether ordinary SiHF-J or a screened instrument cable is the better choice.
