Name: China IEC 62930 Solar Cable For Professional PV Installations Manufacturers Suppliers Factory
Brand: GERITEL
SKU: 312580063

Description

Technical Parameters

Certification

resilient microgrid PV cable

PRODUCT REAL SHOT

photovoltaic cable for resilient microgrid

solar array wiring for resilient microgrid

solar battery microgrid solar cable

International PV Cable – For Reliable Module, String and Inverter Connections

This GERITEL WIRE page targets international EPC contractors and distributors looking for dependable photovoltaic wiring in modern DC solar arrays and inverter connections, with a strong focus on iec standard. The page naturally targets solar DC wire and photovoltaic power cable, two buyer phrases commonly associated with professional solar cable selection and project sourcing. A Class 5 tinned-copper conductor supports flexible handling, while cross-linked halogen-free insulation and the outer sheath provide a robust photovoltaic cable structure. The cable is designed for outdoor photovoltaic duty, combining high-voltage DC capability with thermal, UV, ozone and moisture resistance. For project and distribution orders, GERITEL WIRE supports cable marking, reel or drum packaging, specification confirmation and export documentation.

PRODUCT SPECIFICATIONS

solar battery microgrid PV cable

Application

The GERITEL WIRE PV H1Z2Z2-K cable, which is TUV certifiedaccording to EN 50618 and AENOR certified according to IEC62930, it is suitable for both fixed and mobile solar installations(solar farms, rooftop solar installations and floating plants).It is a highly flexible cable compatible with all major connectorsand specially designed for the connection of photovoltaic panels.

This versatile single-conductor cable is designed to meet the varying needs of the solar industry.

Suitable for wet, damp and humid locations.

Solar PV installations string cable.

SPECIFICATIONS
Conductor	Electrolytic annealed tinned copper, class 5 (flexible) according toIEC 60228 and EN 60228.
Insulation	Halogen free cross-linked rubber according to table B1 in Annex Bof EN 50618 and IEC 62930.
Outer sheath	Halogen free cross-linked flexible rubber according to table B1 inAnnex B of EN 50618 and IEC 62930. Red or black colour.
Electrical performance	Low voltage: 1,5 (1,8) kV DC. 1,0/1,0 kV AC.
Thermal performance	Maximum conductor temperature:90°C (120°C during 20.000 h).Maximum short-circuit temperature: 250°C (max. 5 s).Minimum service temperature: -40°C (fixed and protected installations).
Fire performance	Flame non-propagation according to EN 60332-1-2 / IEC 60332-1-2. Fire non-propagation according to EN 50399.Reaction to fire CPR: Caa-slb, d2, al according to EN 50575.Low smoke halogen free according to EN 60754-1/IEC 60754-1.Low corrosive gases emission according to EN 60754-2 / IEC60754-2. Low smoke emission according to EN 61034 /IEC 61034: Light transmittance > 60%.
Mechanical performance	Minimum bending radius: 4x cable diameter (cable diameter ≤ 8 mm) 5x cable diameter (8 < cable diameter s 12 mm) 6x cable diameter (cable diameter >12 mm). Impact resistance: AG2 Medium severity.
Environmental performance	Chemical & Oil resistance: Excellent. Grease & mineral oils resistance: Excellent. Ozone resistant according to EN 50618. UV Resistant according to EN 50618 and IEC 62930. Water resistance: AD7+ Immersion. AD8 Submersion.
Installation conditions	Open Air. Buried. In conduit.

Conductor	Conductor Stranding	Insulation Thickness	Jacket Thickness	Nominal O.D.	Approx Net Weight	Allowable Ampacities(1) @30℃ Ambient
Nominal Area(mm2)	Number of Strands	mils	mils	Inch	lbs/1000ft	75℃	90℃
1X1.5	1.57	0.7	0.8	4.7	38	860	0.86	13.7
1X2.5	2.04	0.7	0.8	5.2	45	690	0.69	8.21
1X4	2.6	0.7	0.8	5.6	60	580	0.58	5.09
1X6	3.16	0.7	0.8	6.3	90	500	0.50	3.39
1X10	4.5	0.7	0.8	7.6	131	420	0.42	1.95
1X16	5.7	0.7	0.9	9.0	187	340	0.34	1.24
1X25	7.2	0.9	1.0	11.2	267	340	0.34	0.795
1X35	8.5	0.9	1.1	12.7	368	290	0.29	0.565
1X50	9.4	1.0	1.2	14.5	560	270	0.27	0.393
1X70	11.1	1.1	1.2	16.5	756	250	0.25	0.277
1X95	13.1	1.1	1.3	18.7	1036	220	0.22	0.210
1X120	14.8	1.2	1.3	20.4	1309	210	0.21	0.164
1X150	16.5	1.4	1.4	22.7	1636	210	0.21	0.132
1X185	18.3	1.6	1.6	25.2	2000	200	0.20	0.108
1X240	21.0	1.7	1.7	28.5	2607	200	0.20	0.0817
2X1.5	1.57	0.7	0.8	4.8*10.5	78	860	0.86	13.7
2X2.5	2.04	0.7	0.8	5.2*11.8	92	690	0.69	8.21
2X4	2.6	0.7	0.8	5.6*12.8	122	580	0.58	5.09
2X6	3.16	0.7	0.8	6.3*13.7	182	500	0.50	3.39
2X10	4.5	0.7	0.8	8.0*16.8	264	420	0.42	1.95
2X16	5.7	0.7	0.9	9.0*19.8	376	340	0.34	1.24

CERTIFICATIONS

TÜV solar cable for solar battery microgrid

PACKAGING

photovoltaic cable for solar battery microgrid

1,Roll

solar array wiring for solar battery microgrid

Small Wooden Reel

distributed energy microgrid solar cable

Large Wooden Reel

APPLICATION

Residential Rooftop Solar System

TÜV solar cable for distributed energy microgrid

Solar Carport + EV Charging

photovoltaic cable for distributed energy microgrid

Utility-Scale Solar Far

CASE

solar array wiring for distributed energy microgrid

Mauritius Henrietta Solar Power Plant Wire Export

Somalia Mogadishu Solar PV System Project

Tunisia Hammamet New City Industrial Park Solar PV Project

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

TÜV solar cable for solar EV charging station

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

photovoltaic cable for solar EV charging station

solar array cable for solar EV charging station

TÜV solar cable for solar carport EV charging

photovoltaic cable for solar carport EV charging

GLOBAL CERTIFICATIONS

solar array cable for solar carport EV charging

CUSTOMER PHOTOS

PV carport charging station solar cable

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

TÜV solar cable for PV carport charging station

photovoltaic cable for PV carport charging station

solar array cable for PV carport charging station

TÜV solar cable for solar powered EV charger

photovoltaic cable for solar powered EV charger

solar array cable for solar powered EV charger

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

TÜV solar cable for EV charging microgrid

FAQ

Does the cable have a metal shield?

Standard H1Z2Z2-K is normally an unshielded solar cable. PV string circuits are designed around insulated conductors and suitable routing/connector systems rather than a metallic screen, unless a particular project specifies another cable construction. GERITEL WIRE can review the buyer's voltage, route length, current and installation environment before recommending a suitable cable size.

Does it have armor?

Standard H1Z2Z2-K is not normally an armoured solar cable. Where impact, rodent or burial risks require additional mechanical protection, the installation method or a purpose-designed protected cable should be selected rather than assuming the standard sheath acts as armor. For distributors and EPC buyers, GERITEL WIRE can provide specification confirmation, project packaging and documentation support.

Can I order the cable with custom printing?

Yes, OEM solar cable marking can usually include brand, designation, voltage and other agreed information, subject to certification and traceability requirements. The printed text should not create a false approval claim that is not covered by the certificate. GERITEL WIRE focuses on matching the ordered construction to the applicable certificate and can provide supporting technical documents for project review.

Can the cable be supplied as red and black matched pairs?

Yes, red and black PV cable can be supplied as matched reels or drums for positive/negative circuit identification. Packing the pair together can simplify distributor stock control and project installation. GERITEL WIRE can assist with OEM marking and packaging while keeping the electrical construction aligned with the approved product specification.

Hot Tags: iec 62930 solar cable for professional pv installations, China iec 62930 solar cable for professional pv installations manufacturers, suppliers, factory, solar cable, Solar Cable 1500V H1Z2Z2 K TUV UL EN 50618 Solar PV Cable, tuv solar cable
