630mm² single core orange cable

PRODUCT REAL SHOT

1x630mm² XLPE PVC orange cable

630mm2 Extra-Large Power Cable

The 630mm2 single core orange power cable is intended for extra-high-capacity low-voltage connections such as transformer outlets, substation equipment, large switchboards and heavy industrial distribution. Its large stranded copper conductor delivers dependable conductivity, while XLPE insulation and the orange PVC sheath provide thermal and mechanical protection. GERITEL WIRE works with the buyer and engineer to confirm conductor class, cable dimensions, allowable drum length, termination requirements and installation constraints. Factory testing, inspection support and traceable marking are available. Reinforced wooden drums help reduce transport damage and improve handling efficiency.

PRODUCT SPECIFICATIONS

630mm² 1 core XLPE PVC cable

Application

XLPE Single Core Copper Power Cables are designed for reliablelow-voltage and medium-voltage power distribution in commercial,industrial, and infrastructure installations. Their cross-linkedpolyethylene insulation provides excellent thermal performance,electrical strength, and resistance to moisture and chemicals, makingthem suitable for use in enclosed and unenclosed cable trays,conduits, switchboards, and underground systems. These cables arecommonly used for mains and sub-mains feeders, transformer andswitchgear connections, and high-capacity distribution circuits whererobust current-carrying capability and long-term durability areessential.

SPECIFICATIONS
Conductor	Plain Annealed Copper
Insulation	X-90 XLPE Natural
Sheath	5V-90 PVC Black
Voltage	600V/1000V(0.6/1kV)
Temp	-40°C to +90°C
Standards	AS/NZS 5000.1, AS/NZS 1125, AS/NZS 3808, AS/NZS 1660
Greenstar	Approved
VCA	Approved

SIZE mm²	INSULATION THICKNESS mm	SHEATH THICKNESS mm	O.D. mm	MIN BEND RADIUS


6	0.7	1.4	6.8±10%	61
10	0.7	1.4	7.3±10%	66
16	0.7	1.4	9.3±10%	112
25	0.9	1.4	11.4±10%	137
35	0.9	1.4	12.3±10%	148
50	1.0	1.4	13.7±10%	165
70	1.1	1.4	15.7±10%	188
95	1.1	1.5	17.7±10%	212
120	1.2	1.5	19.6±10%	235
150	1.4	1.6	21.8±10%	262
185	1.6	1.6	24.0±10%	270
240	1.7	1.8	27.0±10%	304
300	1.8	1.9	29.9±10%	331
400	2.0	1.9	33.5±10%	375
500	2.2	2.0	37.2±10%	419
630	2.4	2.2	42.0±10%	467

CERTIFICATIONS

630mm² orange SDI cable

PACKAGING

630mm² single core double insulated cable

Plastic Reel

Small Wooden Reel

Large Wooden Reel

APPLICATION

Industrial Equipment Power Supply

Warehouse Electrical Distribution

single core cable for cable tray installation

Water Treatment Pump System

CASE

Mondelēz Manufacturing & Distribution Facility

can single core XLPE cable be buried direct

Portside Distribution Centre

Western Sydney Recycled Water Scheme

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

single core cable minimum order quantity

GLOBAL CERTIFICATIONS

what is orange single core cable used for

CUSTOMER PHOTOS

where is single core orange cable used

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

is single core orange cable suitable for mains

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

is single core cable suitable for submains

can orange single core cable be installed underground

how to select single core cable for mains

can single core cable be installed on cable tray

is orange single core cable UV resistant

is XLPE PVC single core cable waterproof

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

single core cable for unenclosed installation

FAQ

What is the maximum size GERITEL WIRE can quote?

Large sizes up to 630mm2 can be discussed for the applicable construction, subject to production and certification confirmation. GERITEL WIRE provides the single core orange cable diameter, weight, drum length and termination considerations with the quotation.

Why does 630mm2 cable need special handling?

A 630mm2 conductor has significant weight, diameter and bending-force requirements, so drum handling, pulling equipment, route geometry and terminations must be planned. GERITEL WIRE can recommend practical packing lengths for the 630mm2 orange power cable based on project logistics.

Can you provide outside diameter and cable weight?

Yes. GERITEL WIRE can include approximate overall diameter, cable mass and drum data in the single core orange power cable technical sheet. These values help customers select conduits, glands, lugs, pulling equipment and transport arrangements.

Can you calculate how many metres fit on one drum?

Yes. Drum capacity depends on cable diameter, drum size, safe loading and shipping limits. GERITEL WIRE can calculate a suitable drum length for the single core orange cable and provide a packing list showing metres, gross weight and drum dimensions.
