Name: China 16mm Solar DC Cable 1500V DC Flexible Tinned Copper Wire Manufacturers Suppliers Factory
Brand: GERITEL
SKU: 312584688

Description

Technical Parameters

Certification

H1Z2Z2-K 1x16mm2 solar cable

PRODUCT REAL SHOT

EN 50618 solar cable 16mm2

16mm² Tinned Copper Solar Cable for Reliable Rooftop PV Connections

Designed for high-capacity PV feeders, GERITEL WIRE offers this 16mm² single-core option for commercial and industrial solar installations. The 16mm² flexible solar cable targets reliable DC transmission where installers need flexibility and long outdoor service. GERITEL WIRE uses flexible Class 5 tinned copper with halogen-free cross-linked insulation and an outdoor-duty cross-linked sheath. The cable is designed for 1.5kV DC photovoltaic circuits with 90°C thermal performance plus UV, ozone and water resistance. Buyers searching for IEC 62930 solar cable can match this size to project current, route length and voltage-drop requirements. GERITEL WIRE focuses on consistent construction, practical packaging and export-oriented technical support..

PRODUCT SPECIFICATIONS

IEC 62930 solar cable 16mm2

Applications

For general wiring, unenclosed, enclosed in conduit,for domestic, commercial and industrial installations where not subject to mechanical damage.

SPECIFICATIONS
Cable description	PVC insulated laid flat and PVC sheathed cableto A5/NZ5 5000.2
Approvals	A5/NZS5000.2
Behaviour in flame and fire	Flame retardant
Temperature range	Normal operating temperature: +90°C Minimum operating temperature: 0°C
Flexibility	Semi-rigid
Resistance to	Chemical exposure: Occasional Mechanical impact: Light Water exposure:Occasional condensation Solar radiation and weather exposure:Occasional
Cable design	Conductor: Plain annealed copper conductor to AS/NZS 1125Can also be operated at temperatures up to 90°Cwhen not exposed to mechanical deformation(see AS/NZS 3008.1). Insulation: V-90 PVC Colours: Red, Black Sheath: 3V-90PVC Colour: White
Installation conditions	In free air In conduit In ground with protection In duct External building with protection

	Conductor
Insulation Colours	Conductor			Cable						Min. installed bending radius(a) mm
	Nominal C.S.A mm²	Nominal diameter of wires No/mm	Nominal diameter mm	Nominal insulation thickness mm	Overall diameter mm				Approx. mass kg/100m
					Minimum		Maximum
					Major axis	Major axis	Major axis	Major axis
TWIN FLAT PVC
Red,Black	1.0	7/0.42	1.26	0.6	6.4	4.2	6.6	4.3	5.2	15
Red,Black	1.5	7/0.50	1.56	0.6	7.1	4.5	7.3	4.6	6.4	20
Red,Black	2.5	7/0.67	2.0	0.7	8.7	5.4	8.9	5.5	10	20
Red,Black	4	7/0.85	2.6	0.8	10.4	6.3	10.7	6.5	15	25
Red,Black	6	7/1.04	3.1	0.8	11.5	6.9	11.9	7.1	20	30
Red,Black	10	7/1.35	4.1	1	14.2	8.4	15.0	8.8	31	35
Red,Black	16	7/1.70	5.1	1	16.7	9.7	17.3	10.0	45	40
TWIN ACTIVE FLAT PVC
Red, White	1.0	7/0.42	1.26	0.6	6.4	4.2	11.7	4.3	5.2	15
Red, White	1.5	7/0.50	1.56	0.6	7.1	4.5	12.8	4.6	6.4	20
Red, White	2.5	7/0.67	2.0	0.7	8.7	5.4	15.8	5.5	10	20
Red, White	4	7/0.85	2.6	0.8	10.4	6.3	18.3	6.5	15	25
Red, White	6	7/1.04	3.1	0.8	11.5	6.9	20.1	7.1	20	30
Red, White	10	7/1.35	4.1	1.0	14.2	8.4	25.8	8.8	31	35
Red, White	16	7/1.70	5.1	1.0	16.7	9.7	17.3	10.0	45	40

CERTIFICATIONS

1500V DC solar cable 16mm2

PACKAGING

Roll

Plastic Reel

Small Wooden Reel

APPLICATION

Capsule Accommodation

Prefabricated Housing

Recreational Vehicle Wiring

CASE

2020 Ford Transit AWD Camper Van Conversion

Epping Forest District Council Modular Homes

Wethersfield Modular Accommodation Deployment

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

photovoltaic cable for ground mounted PV plant

GLOBAL CERTIFICATIONS

floating solar plant cable

CUSTOMER PHOTOS

floating solar plant PV cable

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

photovoltaic cable for floating solar plant

photovoltaic cable for agrivoltaic solar farm

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

Can the cable be used for a retrofit solar project?

Yes, but a retrofit should first confirm the existing system voltage, connector family, polarity, cable size, insulation condition and local rules. A solar installation cable should not be selected only by matching the color or outside diameter of the old cable. GERITEL WIRE can review the buyer's voltage, route length, current and installation environment before recommending a suitable cable size.

Does the cable work with all solar panel brands?

Solar panel cable selection is generally based on electrical and connector compatibility rather than the panel brand alone. Confirm the connector system, conductor cross-section, voltage rating and project specification before making extensions or replacements. For distributors and EPC buyers, GERITEL WIRE can provide specification confirmation, project packaging and documentation support.

Is TÜV Solar Cable suitable for residential solar?

Yes. Residential solar cable is widely used for rooftop module strings and DC wiring to the inverter. For a home project, the installer still needs to calculate current, voltage drop and routing conditions instead of assuming one cable size fits every roof. GERITEL WIRE focuses on matching the ordered construction to the applicable certificate and can provide supporting technical documents for project review.

Is it suitable for commercial solar rooftops?

Yes. Commercial rooftop PV cable needs durable outdoor performance and an appropriate fire/installation classification for the building. H1Z2Z2-K is commonly used on large rooftop arrays when the project standard and cable size are correctly specified. GERITEL WIRE can assist with OEM marking and packaging while keeping the electrical construction aligned with the approved product specification.
