SiHF-J cable for aircraft construction

PRODUCT REAL SHOT

high temperature cable for aircraft construction

silicone control cable for aircraft construction

SiHF-J cable for aviation equipment

Shipbuilding Heat Resistant Cable for Galley, HVAC and Machinery Connections

Engine rooms, galleys and refrigeration spaces place local equipment wiring near heat, oil and changing ambient temperatures. GERITEL WIRE produces a vessel refrigeration cable with fine stranded tinned copper conductors, silicone core insulation and a silicone outer sheath for flexible installation in controlled, low-stress routes. It can also be considered as a ship galley equipment cable for heaters, ovens, fans and auxiliary panels when the electrical and environmental conditions match. The SiHF-J designation alone does not provide a marine class approval, so shipyards should confirm flag, class, flame, smoke and installation requirements for each project. Samples and construction records are available for the buyer's engineering review.

PRODUCT SPECIFICATIONS

high temperature cable for aviation equipment

Applications

This cable is used for connection of electrical appliances without mechanical stress at increased environmental temperatures, for example in steelworks, but also at low temperatures. Insulation and sheath are resistant to most oils,acids, lyes and oxidants.

SPECIFICATIONS
Voltage Rating Uo/U	300/500V
Temperature Rating	Fixed:-60°C to +200°C
Minimum Bending Radius	Fixed: 5 x overall diameter Flexed: 15 x overall diameter
Conductor	Class 5 flexible Stranded Tinned Copper
Insulation	Silicone rubber
Outer Sheath	Silicone Rubber
Core ldentification	3 cores: Green/Yellow,Blue,Brown 4cores: Green/Yellow,Blue,Black,Grey 5cores: Green/Yellow,Blue,Brown,Black,Grey More than 5 cores: Black numebered +Green/Yellow
Sheath Colour	Red,Black

DIMENSIONS

NO. OF CORES
NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
3	0.75	6.8	66
3	1	7.4	78
3	1.5	8	98
3	2.5	9.7	152
3	4	11.5	249
3	6	14.2	352
4	0.75	7.8	84
4	1	8	95
4	1.5	8.8	122
4	2.5	10.6	189
4	4	13	330
4	6	16.2	429
4	10	21.4	710
4	16	24	1014
4	25	29.3	1460
4	35	33	2044
4	50	34	2990
5	0.75	8.5	101
5	1	8.8	116
5	1.50	9.6	148
5	2.5	11.6	229
5	4	15	359
5	6	17.7	564
5	10	22.5	900
5	16	26.9	1206
5	35	36.7	2850
7	0.75	9.6	158
7	1	10	177
7	1.5	10.9	232
7	2.5	13.2	348
7	4	16.2	487
7	6	19.3	685
12	0.75	11.1	178
12	1.5	14.8	332
12	2.5	18	530
18	0.75	13.3	260
18	1.5	17.6	510
24	1.5	20.2	635
25	0.75	15.6	370

CERTIFICATIONS

red brown silicone multicore cable

PACKAGING

red brown high temperature silicone cable

Roll

halogen free SiHF-J silicone compound cable

Plastic Reel

SiHF-J cable with halogen free silicone compound

Small Wooden Reel

APPLICATION

halogen free silicone compound multicore cable

HVAC & Refrigeration Systems

high temperature halogen free silicone compound cable

Industrial Automation & Machinery

Industrial Control Cabinet Wiring

CASE

SiHF-J cable with flame retardant silicone compound

Northern Steel High-Temperature Control Upgrade Project

flame retardant silicone compound multicore cable

OceanStar Marine Electrical Retrofit Project

high temperature flame retardant silicone compound cable

PolarFresh Industrial Refrigeration Expansion Project

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

SiHF-J unscreened silicone control cable

unscreened silicone multicore control cable

unscreened high temperature control cable

screened silicone control cable alternative

shielded silicone multicore cable alternative

GLOBAL CERTIFICATIONS

high temperature screened control cable alternative

CUSTOMER PHOTOS

SiHF-J cable for fixed installation

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

fixed installation silicone multicore cable

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

fixed laying high temperature silicone cable

flexible installation silicone multicore cable

flexible application silicone control cable

SiHF-J cable for dry humid and wet rooms

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

What minimum bending radius should I use?

For the GERITEL construction, the SiHF-J cable bending radius is listed as 5 times overall diameter for fixed routing and 15 times overall diameter when flexed. Use the finished-cable diameter from the approved datasheet, avoid kinks, and ask GERITEL WIRE to confirm the limit for the exact ordered size.

Can SiHF-J be installed permanently in cable tray?

A fixed installation silicone cable can be routed in a protected tray when voltage, temperature, support spacing, bend radius and local code are satisfied. GERITEL WIRE recommends protecting it from sharp tray edges and heavy cables, and can provide the outer diameter needed for tray-fill and clamp planning.

Can I use this cable in a drag chain?

Standard SiHF-J should be treated as an occasional flexing cable, not a continuous drag-chain cable with defined millions of cycles. GERITEL WIRE asks for travel distance, speed, acceleration and bend radius; if continuous motion is required, we will recommend evaluating a purpose-designed moving cable instead.

Can the cable be pulled under tension during operation?

The intended application is silicone cable without tensile stress. It may be routed during installation, but it should not carry suspended loads or experience continuous pulling in service. GERITEL WIRE helps buyers plan strain relief, support spacing and termination anchoring so the conductor and soft silicone sheath are not overloaded.
