CU EPR/CTS/PVC Power Type MV-105 3 Conductor 15kV 133% I.L. 220 mils Shielded
PRODUCT SPECIFICATIONS
Product Description
The 3 Conductor MV-105 Power Cables consist of fully annealed bare copper Class B stranded conductors, covered with ethylene propylene rubber (EPR), copper tape shield, and black PVC jacket. These cables are used in industrial power circuits.
Applications
- In conduit, duct, free air, direct burial and raceways, primary installations include cable trays, and outdoor locations
- In wet or dry locations
- Approved for Class I, Div. 2 industrial hazardous locations per NEC
- Designed to operate continuously at a conductor temperature not exceeding
105°C for normal operations
140°C for emergency overload
250°C for short circuit
Features
- Rated at 105°C wet or dry
- Excellent corona resistance
- High dielectric strength
- Low moisture absorption
- Low dielectric loss
- Excellent sunlight resistance
- For CT USE per UL 1072
- Meets cold bend test at -35°C
- For direct burial applications
| SPECIFICATIONS | |
|
Conductor Count |
3 conductor |
|
Conductor |
Fully annealed bare copper Class B compressed strand (filled or unfilled) |
|
Gauge Sizes |
Available in 2 AWG through 750 kcmil |
|
Conductor Strand Shield |
Extruded thermoset semi-conducting polymer over the conductor |
|
Insulation |
Ethylene Propylene Rubber (EPR) |
|
Insulation Shield |
Extruded thermoset semi-conducting polymer over the insulation |
| PhaseIdentification | Color ribbonsin each phase(standard: black-red-blue) |
|
Shield |
5 mil annealed copper tape helically applied with approximately 25% overlap |
| Fillers | Non-hygroscopic fillers, as necessary to obtain a circular cross section |
| Ground Conductor | Uninsulated bare copper ground |
|
Overall Jacket |
Polyvinyl Chloride (PVC) |
|
Jacket Marking |
00000 FT GREATER WIRE XXAWG (or XXXKCMIL) 3/C XXKV XXX% INSUL LEVEL XXXMILS EPR/PVC JKT TYPE MV-105 FOR CT USE (UL) SUN RES DIR BUR MADE IN USA MMDDYYYY (LIGHTNING BOLT) |
|
Packaging |
Non-returnable wood reels in a variety of lengths and dimensions |
|
Performance Compliances |
ASTM B3 | ASTM B8 UL 1685 (flame exposure test) |
|
Other Compliances |
EPA 40 CFR, Part 261 OSHA |
Copper Cdr 15kV 133% I.L. 220 mils Shielded
|
Conductor AWG/Kcmil |
Nom.Conductor in(mm) |
Insulation Diameter in(mm) |
Ground Wire AWG |
Jacket Thickness in(mm) |
Approx.Overall |
Approx. Net Weight | Ampacity | ||
| lbs/kft(kg/km) |
Conduit in Air |
Underground Duct | Tray | ||||||
| 2 | 0.283 (7.2) | 0.78 (19.8) | 6 | 0.105(2.7) | 2.11 (53.6) | 2,220(3,303) | 160 | 185 | 185 |
| 1 | 0.322(8.2) | 0.82 (20.8) | 4 | 0.105(2.7) | 2.20 (55.9) | 2,520(3,750) | 185 | 210 | 210 |
| 1/0 | 0.362(9.2) | 0.86 (21.8) | 4 | 0.105(2.7) | 2.28 (57.9) | 2,815(4,189) | 210 | 240 | 240 |
| 2/0 | 0.405(10.3) | 0.90 (22.9) | 4 | 0.105(2.7) | 2.38 (60.5) | 3,175(4,724) | 235 | 275 | 275 |
| 3/0 | 0.456 (11.6) | 0.96(24.4) | 3 | 0.105(2.7) | 2.49 (63.2) | 3,650 (5,431) | 270 | 315 | 315 |
| 4/0 | 0.512(13.0) | 1.01 (25.7) | 3 | 0.105(2.7) | 2.62 (66.5) | 4,195 (6,242) | 305 | 360 | 360 |
| 250 | 0.558(14.2) | 1.07 (27.2) | 2 | 0.105(2.7) | 2.74 (69.6) | 4,730 (7,038) | 335 | 400 | 400 |
| 350 | 0.661 (16.8) | 1.17 (29.7) | 2 | 0.130(3.3) | 3.02(76.7) | 6,055(9,010) | 400 | 490 | 490 |
| 500 | 0.789 (20.0) | 1.30 (33.0) | 1 | 0.130(3.3) | 3.30 (83.8) | 7,830 (11,651) | 485 | 600 | 600 |
| 750 | 0.968 (24.6) | 1.50(38.1) | 1/0 | 0.130(3.3) | 3.71 (94.2) | 10,730 (15,966) | 585 | 745 | 745 |
