Name: China Food Processing Silicone Cable For Industrial Cooking And Drying Equipment Manufacturers Suppliers Factory
Brand: GERITEL
SKU: 314326563

Description

Technical Parameters

Certification

silicone control cable for air handling units

PRODUCT REAL SHOT

green yellow earth conductor silicone cable

green yellow earth conductor SiHF-J cable

Commercial Bakery Equipment Cable for Ovens, Warmers and Control Panels

Commercial food machinery uses heaters, fans, temperature sensors and compact controls that may operate for long periods near warm surfaces. GERITEL WIRE supplies an industrial cooking equipment cable made with flexible tinned copper conductors, silicone rubber insulation and a silicone sheath for equipment-level connections. It can be evaluated for ovens, proofers, warming tunnels, dryers and bakery lines where routing is fixed or only occasionally moved without tensile stress. The food drying machine silicone cable is an electrical component and is not automatically approved for direct food contact; hygienic design, cleaning chemicals, glands and local approvals must be checked separately.

PRODUCT SPECIFICATIONS

green yellow earth conductor multicore silicone cable

Applications

This cable is used for connection of electrical appliances without mechanical stress at increased environmental temperatures, for example in steelworks, but also at low temperatures. Insulation and sheath are resistant to most oils,acids, lyes and oxidants.

SPECIFICATIONS
Voltage Rating Uo/U	300/500V
Temperature Rating	Fixed:-60°C to +200°C
Minimum Bending Radius	Fixed: 5 x overall diameter Flexed: 15 x overall diameter
Conductor	Class 5 flexible Stranded Tinned Copper
Insulation	Silicone rubber
Outer Sheath	Silicone Rubber
Core ldentification	3 cores: Green/Yellow,Blue,Brown 4cores: Green/Yellow,Blue,Black,Grey 5cores: Green/Yellow,Blue,Brown,Black,Grey More than 5 cores: Black numebered +Green/Yellow
Sheath Colour	Red,Black

DIMENSIONS

NO. OF CORES
NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
3	0.75	6.8	66
3	1	7.4	78
3	1.5	8	98
3	2.5	9.7	152
3	4	11.5	249
3	6	14.2	352
4	0.75	7.8	84
4	1	8	95
4	1.5	8.8	122
4	2.5	10.6	189
4	4	13	330
4	6	16.2	429
4	10	21.4	710
4	16	24	1014
4	25	29.3	1460
4	35	33	2044
4	50	34	2990
5	0.75	8.5	101
5	1	8.8	116
5	1.50	9.6	148
5	2.5	11.6	229
5	4	15	359
5	6	17.7	564
5	10	22.5	900
5	16	26.9	1206
5	35	36.7	2850
7	0.75	9.6	158
7	1	10	177
7	1.5	10.9	232
7	2.5	13.2	348
7	4	16.2	487
7	6	19.3	685
12	0.75	11.1	178
12	1.5	14.8	332
12	2.5	18	530
18	0.75	13.3	260
18	1.5	17.6	510
24	1.5	20.2	635
25	0.75	15.6	370

CERTIFICATIONS

high insulation resistance silicone cable

PACKAGING

Roll

high insulation resistance multicore silicone cable

Plastic Reel

stable electrical performance silicone cable

Small Wooden Reel

APPLICATION

stable electrical performance SiHF-J cable

HVAC & Refrigeration Systems

stable electrical performance multicore silicone cable

Industrial Automation & Machinery

Industrial Control Cabinet Wiring

CASE

Northern Steel High-Temperature Control Upgrade Project

industrial duty multicore silicone cable

OceanStar Marine Electrical Retrofit Project

PolarFresh Industrial Refrigeration Expansion Project

WHY CHOOSE US

30Years of experience
in one-stop service

Dongguan Greater Wire & Cable Co., Ltd. is a professional engineering-grade cable manufacturer in China, supplying certified electrical cable solutions for building, industrial, mining, energy, and infrastructure projects worldwide.

With a 30,000 m² factory, 30 production lines, experienced engineers, and a strict quality control team, we provide reliable, traceable, and compliant cable products for international engineering applications. Our products are supported by certifications including SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, and ISO.

We are committed to safety, quality, transparency, and long-term partnership. From raw material inspection to finished product testing, every batch is carefully controlled to ensure stable performance and dependable project use.

Greater Cable - Certified Quality. Reliable Supply. Engineering Value.

15K

Finished Projects

150+

professional staff

15K

happy clients

92+

awards & certifacates

PLANT EQUIPMENT

harsh environment multicore silicone cable

temperature fluctuation resistant silicone cable

temperature fluctuation resistant SiHF-J cable

temperature fluctuation resistant multicore silicone cable

GLOBAL CERTIFICATIONS

thermal aging resistant multicore silicone cable

CUSTOMER PHOTOS

fire safety silicone cable

INTERNATIONL TRANSPORTATION

Sea Freight

We offer reliable sea freight solutions for large-volume orders. Your goods are securely packed and shipped in containers, ensuring cost-effective delivery to ports worldwide.

Air Freight

For faster delivery, our air freight service ensures your products reach international destinations quickly, with careful handling and full tracking along the way.

International Express

Need urgent shipments? Our international express service delivers small to medium orders efficiently, providing door-to-door service with real-time tracking for peace of mind.

COOPERATIVE PARTNER

We are looking for a cooperative partner to expand our business.

long service life multicore silicone cable

SiHF-J cable with Class 5 tinned copper conductor

Class 5 tinned copper silicone multicore cable

high temperature cable with Class 5 tinned copper conductor

SiHF-J cable with fine stranded tinned copper conductor

high temperature fine stranded tinned copper cable

How To Cooperate With Us?

Simply share your requirements, receive our professional solution, confirm samples, and enjoy fast, reliable production and worldwide delivery - working with us is that easy.

Our address

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, China

Phone Number

+86 136 6257 9592

+86 135 1078 4550

E-mail

manager01@greaterwire.com

FAQ

Is the outer jacket also made of silicone?

Yes. The standard GERITEL product is a silicone outer sheath cable with silicone-insulated cores beneath the jacket. This gives one consistent heat-resistant construction, but it does not make the cable armoured, screened or abrasion-proof. GERITEL WIRE confirms the route and recommends added mechanical protection when required.

How flexible is the conductor compared with building wire?

A flexible multicore tinned copper cable uses Class 5 fine strands, making it easier to route than solid or Class 2 fixed building wire. The assembled cable still has minimum bending-radius and movement limits. GERITEL WIRE can send a sample so panel shops and equipment OEMs can test routing and termination.

How are cores identified when there are more than five conductors?

For higher core counts, a numbered core silicone cable commonly uses black cores with consecutive numbers plus a green/yellow protective conductor where required. GERITEL WIRE confirms the exact colour and numbering schedule on the order drawing, avoiding wiring errors during machine assembly.

Does the J version always include a green/yellow conductor?

The "J" designation normally identifies a green yellow earth core cable configuration. Core count and protective-conductor arrangement must still be stated clearly on the purchase order. GERITEL WIRE sends the construction and colour schedule for approval so the delivered cable matches the equipment wiring diagram.

Hot Tags: food processing silicone cable for industrial cooking and drying equipment, China food processing silicone cable for industrial cooking and drying equipment manufacturers, suppliers, factory
