1. What is XHHW-2?
XHHW-2 stands for Cross-linked High Heat and Water-resistant, Version 2. It is an electrical cable with thermoset XLPE (cross-linked polyethylene) insulation, offering superior resistance to heat, water, and physical stress. XHHW-2 is approved for dry and wet locations and is widely used in conduit systems and underground (xhhw 2 underground) applications.
Key Features:
Rated for 600V, 1,000V, or 2,000V systems
Designed for 90°C operation in both dry and wet conditions
Available in copper or aluminum conductors
Complies with UL 44 and NEC Article 310
2. XHHW-2 Cable Voltage Rating
The voltage rating is one of the most critical specifications in the xhhw 2 wire specification. It defines the maximum electrical pressure the cable can withstand:
Standard Voltage Ratings: 600V, 1,000V, or 2,000V
Common Applications:
600V: Residential and light commercial wiring
1kV–2kV: Industrial power distribution and transformer feeds
XHHW-2's voltage rating must align with UL and NEC safety standards (such as NEC 310.10), ensuring safe operation in both enclosed conduit and xhhw 2 underground applications.
3. XHHW-2 Cable Temperature Rating
The temperature rating defines the cable's capacity to maintain performance under thermal stress.
| Environment | XHHW-2 Temperature Rating |
|---|---|
| Dry Locations | 90°C |
| Wet Locations | 90°C |
| Ambient/Underground | Stable up to 90°C |
Compared to standard XHHW, XHHW-2 offers a consistent 90°C rating in both dry and wet environments, enhancing safety and longevity in underground (xhhw 2 underground) and outdoor installations.
4. XHHW-2 Conductor and Ampacity: Copper vs. Aluminum
XHHW-2 is available in copper (xhhw 2 copper wire) and aluminum options. Copper offers superior conductivity and flexibility, making it ideal for high-performance systems.
Ampacity Table (90°C Rating):
| Size (AWG/kcmil) | Copper Ampacity | Aluminum Ampacity |
|---|---|---|
| 2 AWG | 115A | 90A |
| 1/0 AWG | 150A | 120A |
| 4/0 AWG | 230A | 180A |
Example – Underground Use:
In a residential subdivision project, 4/0 AWG XHHW-2 copper wire was installed in 3-ft-deep PVC conduit to supply power to multiple buildings. The cable maintained voltage integrity and safe current capacity despite long-distance runs and high ambient temperatures.
5. XHHW-2 Mechanical & Environmental Ratings
The xhhw 2 wire specification outlines robust mechanical and environmental resistance:
UV Resistant – Suitable for outdoor exposure
Moisture Resistant – Ideal for underground conduits and wet environments
Abrasion Resistant – For heavy-duty industrial use
Flexible Construction – Easier to install through conduit
Case Study:
A port logistics warehouse utilized 1/0 AWG xhhw 2 copper wire in both outdoor trays and xhhw 2 underground ducts. The UV and moisture resistance ensured a long service life in the coastal climate.
6. XHHW-2 Wire Specification Overview
The xhhw 2 wire specification covers critical technical properties:
Conductor Material: Stranded copper (Class B) or compact aluminum
Insulation: Cross-linked polyethylene (XLPE)
Voltage Rating: 600V / 1,000V / 2,000V
Temperature Rating: 90°C in dry and wet locations
Minimum Bending Radius: Typically 7x cable outer diameter
Certifications: UL Listed, CSA, RoHS Compliant, NEC 310
Other elements like weight, diameter, color code, and installation temperature range are also included in detailed product sheets for procurement or design documentation.
7. XHHW-2 vs Other Cable Types
XHHW-2 vs THHN
| Feature | XHHW-2 | THHN |
|---|---|---|
| Dry Temp Rating | 90°C | 105°C |
| Wet Temp Rating | 90°C | 75°C |
| Underground Rated | Yes (xhhw 2 underground) | No (conduit required) |
| Insulation | XLPE | Nylon over PVC |
XHHW-2 vs USE-2 / RHW-2 / RWU90
XHHW-2 vs USE-2: XHHW-2 offers better flexibility and conduit compatibility
XHHW-2 vs RHW-2/RWU90: Similar wet-location ratings, but XHHW-2 is easier to handle during installation
8. Applications and Installation Guidelines: xhhw 2 underground & More
Typical Uses:
Commercial and industrial power distribution
Subpanel feeder circuits
Service entrance conductors
xhhw 2 underground duct banks or PVC conduit systems
Installation Tips:
Use approved conduit for underground installations
Follow minimum bending radius rules
Apply derating for multiple cables in conduit
9. Common Questions About XHHW-2 Cable
Q1: What is the difference between XHHW and XHHW-2?
A: XHHW-2 is rated for 90°C in both wet and dry locations; XHHW is only rated for 75°C in wet locations.
Q2: Is XHHW-2 copper wire suitable for 2,000V applications?
A: Yes, certain xhhw 2 copper wire products are UL-rated up to 2,000V for industrial use.
Q3: Can XHHW-2 be installed underground?
A: Yes, XHHW-2 is UL-approved for xhhw 2 underground use when installed in appropriate conduit.
Q4: What details are included in the xhhw 2 wire specification?
A: Voltage rating, insulation type, conductor material, UL listings, ampacity, and physical dimensions.
