H05V-U cable and H07V-U cable are European standard cables with specific application ranges and performance characteristics. This type of cable is mainly used for internal peripheral hard wiring between electrical and instrument distribution panels and power distribution boards, as well as interfaces between electronic and electrical equipment and switchgear. Meanwhile, it is also applicable to power and lighting systems. The design of H05V-U cable and H07V-U cable takes into account the requirements for fixed installation of exposed and embedded conduits.
Product Structure Description:
Compliant with VDE0295.IEC60228-1 single solid conductor (tin plated) copper wire
Compliant with VDE 0281. HD 21.3&IEC 60227 polyvinyl chloride PVC core wire
Key points of product performance:
H05V-U
Working voltage: 300/500V
H07V-U
Working voltage: 450/750V
Minimum bending radius: 15x cable outer diameter
Temperature range for use:
Mobile installation: -5 ℃ to+80 ℃
Fixed installation: -40 ℃ to+70 ℃
Oil resistance, flame retardancy, and flame retardancy: IEC 60332.1/HD 405.2 and VDE 0207-4
Core color separation:
2-core: blue, brown (brown)
3-core: green/yellow, blue, brown (brown);
4-core: yellow/green, black, brown (brown), blue;
5-core: green/yellow, brown (brown), black, gray, blue
H05V-U cables and H07V-U cables have a wide range of applications, including but not limited to single core wires for power equipment, suitable for connecting and transmitting various power and control circuits, such as electrical equipment and lighting systems in buildings, factories, computer rooms, subways, tunnels, bridges, and other places. In addition, exporting this type of cable to EU countries also requires obtaining CE certification, ensuring that its quality and safety performance comply with European standards.
In summary, h05v u cable and h07v u cable are high-quality cable products, particularly suitable for applications that require high voltage and high temperature tolerance, while ensuring safety and reliability
